Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > 2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr Multi-language

2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr Multi-language

Name: 2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr Multi-language
Brand: GWSECU
SKU: 110163089
Availability: InStock

2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr Multi-language thumbnail-1

2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr Multi-language photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

GWSECU

Model Number:

KD-G6108H-AHD-80E

Contact Supplier Request Quote Chat Now

Shenzhen Guowei Security Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name GWSECU

Model Number KD-G6108H-AHD-80E

2mp HD Analog DVR 8ch 1080P AHD DVR Tribrid AHD Dvr multi-language

Technical Specifications

Model	KD-G6104H-AHD-80E		KD-G6104H-AHD-80	KD-G6108H-AHD-80E
System
Main Processor	Technical grade embedded microprocessor
Operating System	Embedded LINUX
Interface
Operation interface	16bit real color GUI interface support mouse operation
Display screen	1/4 screen (take analog channel as an example, other is base on the selected channel mode)	1/4/ screen (take analog channel as an example, other is base on the selected channel mode)		1/4/9 /16screen (take analog channel as an example, other is base on the selected channel mode)
Video
Video standard	PAL/NTSC(1080P)
Image encode	H.264(High Profile);JPEG
Monitor quality	Monitor:D1;VGA&HDMI:High definition(support 19201080, 1280720,1440900,12801024, 1024768,800600)
Playback quality	1080P/720P/D1/HD1/CIF
Encode capability	4CH 1080p	4CH 10800p		8CH 1080p
Decode capability	4CH 1080p@15FPS	4CH 1080p@30FPS		8CH 1080p@15FPS
Multi-mode video input	Analog:4CH1080P/4CH 720P Digit:4CH1080P/1CH1080P+8CH720P /20CH960H HYBIRD: 2 CH1080P(analog) +2CH1080P(network) /4CH720P+4CH720P	Analog:4CH1080P/4CH 720P Digital:4CH1080P/1CH1080P+8CH720P /20CH960H HYBIRD: 2 CH1080P(analog)+2CH1080P(network) /4CH720P+4CH720P		Analog:8CH1080P@15FPS /4CH1080P@25FPS/8CH720P Digital: 4CH1080P / 1CH1080P+8CH720P /20CH960H HYBIRD: 2CH 1080P(analog)+2CH1080P(network) /8CH720P+8CH*720P)
Motion detection	Each channel can set 192(16*12)detection area; can set multi-level of flexibility (for local analog channel only)
Playback & Record
Record mode	manual>alarm>motion detection>timing
Local playback	1-4ch playback synchronously (take local analog input for example, other is depended on the selected channel mode)	1-9ch playback synchronously (take local analog input for example, other is depended on the selected channel mode)		1-16ch playback synchronously (take local analog input for example, other is depended on the selected channel mode)
Video search	time,date,event,channel search
Audio
Audio compression	G711A
Bidirectional talk	Support
Storage and back up
Space occupation	Video:CIF 4~5G/daychannel, D1 16~20G/daychannel; audio:691.2M/day*channel
Video storage	Local HDD ,Network
Back up mode	Network backup,USB portable HDD,USB imprint,SATA imprint
Interface
Video input	4CH BNC(1.0Vp-p,75Ω)	4CH BNC(1.0Vp-p,75Ω)		8CH BNC(1.0Vp-p,75Ω)
Video output	1CH VGA,1CH HDMI
Audio imput	4CH RCA
Audio output	1CH RCA(200-3000mV,5KΩ)
Alarm input	2CH	2CH		4CH
Alarm output	1CH	1CH		1CH
Network port	RJ45 10M/100M self-adaptive Ethernet port
PTZ control	1 RS485;support multi kinds of PTZ protocol
USB port	2*USB2.0
HDD port	2 SATA ports(each max to 8TB)
Wireless port	3G,WIFI(extension via USB port)
General
Power Supply	DC 12V/4A
Power Consumption	<15W (Without HDD)
Working Environment	0°C~+55°C / 10%~90%RH / 86~106kpa
Dimension (W×D×H)	1U, 325mm×255mm×60mm
Weight	1.6Kg (without HDD)
