Function
Mine plastic buckets for bucket elevators is applied in the vertical conveying of abrasive powder, granular and small lump materials, such as grain, coal, cement and crushed ore, etc., and its transportation height can reach to 28m.The bucket chains are characterized by simple structure, stable operation hybrid or gravity discharge. The wheel rim uses combination sprocket, and it is easy to replace and has been specially treated to ensure a long service life. The underpart is equipped by gravity automatic tensioning device, so that it can maintain a constant tension to avoid slipping off the chain. The material temperature can not exceed 250 °C.
Model |
Speed(m/s) |
Hopper type |
Hopper volum(L) |
Max feeding size(mm) |
Capacity(m³/h) |
| TH315 | 1.1 | <p >SH(deep hopper) | 6 | 35 | 59 |
| TH400 | 1.1 | <p >SH(deep hopper) | 9.5 | 40 | 94 |
| TH500 | 1.5 | <p >SH(deep hopper) | 15 | 50 | 118 |
| TH600 | 1.5 | <p >SH(deep hopper) | 23.6 | 60 | 185 |
The capacity refers to limestone, professing capacity may vary with different materials and feeding sizes. | |||||
Model |
Capacity(m³/h) |
Speed(m/s) |
Max feeding size(mm) |
Hopper volum(L) |
Size of Hopper |
| NE15 | 15 | <p >0.5 | 40 | 2.5 | 250*203 |
| NE30 | 30 | <p >0.5 | 50 | 7.8 | 300*305 |
| NE50 | 50 | <p >0.5 | 50 | 15.7 | 300*305 |
| NE100 | 100 | 0.5 | 70 | 35 | 400*400 |
| NE150 | 150 | 0.5 | 70 | 52.2 | 600*400 |
| NE200 | 200 | 0.5 | 100 | 84.6 | 600*500 |
| NE300 | 300 | 0.5 | 100 | 127.5 | 600*500 |
| NE400 | 400 | 0.5 | 120 | 182.5 | 700*600 |
| NE500 | 500 | 0.5 | 120 | 260.9 | 700*700 |
| NE600 | 600 | <p >0.5 | 120 | 332 | 700*700 |
The capacity refers to limestone, professing capacity may vary with different materials and feeding sizes. | |||||
Operating Principle
While high efficiency hoist plastic buckets for bucket elevators is energized, the driving device drives pulley to make the bucket belt doing the circular motion from bottom to up. The bucket is filled with material and convey to the head terminal, then the material is thrown from the outlet under the action of centrifugal force according to the parabolic design. After discharging, the empty bucket is back to the foot by conveying and be filled again, then the machine do repeated movement just like before.
Features
1. Excellent sealing, less environmental pollution.
2. Easy Operation and maintenance, less wearing parts.
3. Energy conservation and less maintenance ensure the machine a very low cost.
4. Advanced design principle has ensured the reliability of machine operation.
5. High accuracy. The housing case is of good rigidity and beautiful appearance by the edge folding and intermediate beading.
6. Small size. Compared with other machines which have the same lifting capacity, size of this machine is smaller.
7. Transmission capacity. The series hoist NE15~NE800 a variety of specifications. Enhance the volume range of 15 to 800m3 / h.
Our company manufactures various bucket elevators, such as bucket conveyer, bucket type lifter, ore elevator machine, mixing bucket and stone bucket.
Pre-sale:Enthusiastic
We offer you the early planing of the project, the best process flow design, choose the best appropriate equipment model to design products according to your special needs.
Sale: Integrity
All productds have to pass strict inspection with the drawings and process flow according to the contract before they go out. We assigned the technicians to the producing spot to provide installation guide, testing and training.
After-sale:Considerate
To establish good business relationship, we adopt periodical visit to the users. We could give you the definite reply during 24 hours when the users meet some problems in the producing process.
Q: Payment?
A: 30% by TT as deposit on signing the contract, 70% by as final payment of balance after the client's satisfactory inspection of the equipment prior to the goods leaving the factory.
Q: What about Warranty? And what will we do if the machine is broken down?
A: The warranty period for all of structural and mechanical equipment is one year. The warranty period for all electric motors is half one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q: What should we need to do for if we want to get a best quotation?
A: Hi, if you want us recommend a suitable type for you, please let us know the details as follows:
1) The capacity (tons per hour ) do you need?
2) The size of the raw materials and the size of the finished products?
3) What's your main raw materials?(soft or hard materials? water content?)
Q: What could you help me to do for the business?
A: Many thanks for your trust, we can provide you with proposal chart for complete production lines, spot inspection and operator traning according to your demands and the conditions of applied spot, we can help you choose the right equipments, drilling rig, loader, trucks, excavators and so on for rotary washer for sand washing.
Q: Delivery time?
A: Standard delivery time for stationary crusher plant is 30 working days from receipt of deposit, the mobile crusher plant is 45 working days.
