CMD-410 2014 newest product 480 tv lines18 infra-red 1.0 LUX reverse car camera,camera car,camera for car
Product Details
This is car rear view camera for ALL MODELS OF CARS, link with DVD, vehicle GPS, monitor, as a part of rearview system, when you parking the car, this camera will show the image behind the car, and is there anybody behind the car, avoid people crush and some obstacles, it will make your parking more safe and easy!
1. Night vision available and high definition Mini Car Camera. Good driving assistant in the night. Day/Night sensor for automatic adjustment.
2. Smart size for easier installation. It can be mounted on each side of vehicles.
3. Reversing wire is optional.
Features:
1. Small size, easy installation, aesthetic and covert installation.
2. Adopt the United States original chip
3. High-definition and night vision available Mini Car Camera Automatic white balance function.
4. Waterproof (IP68) & dust-proof Mini Car Camera.
5. With 170 degree view angle
6. car reversing distance reference line (optional) Mini Car Camera .
7. Equiped with the same size drill/two screws
Installation Guides:
1. Check to be sure the hole saw used is with equal diameter to that of camera.
2. Adjust the camera to turn the up arrow mark straight upwards
3. Put the harness through the hole made on bumper before fixing the camera.
4. Put the camera into the hole and use your two thumbs to press it evenly to assure a tight and flat mounting.
Accessories:
| 1. AV cable 6 meters, DC cable 1.5 meter |
| 2. The right size drill/two screws |
| 3. User Manual |
Technical parameters | ||
2014 new invention gift, car rear view camera gift | ||
Product Solutions |
CMOS |
CCD |
Image Format |
NTSC/PAL Optional |
NTSC/PAL Optional |
Effective Pixel |
NTSC:580*540 PAL:580*492 |
NTSC:728*580 PAL:728*560 |
Definition |
420 TV Lines |
480 TV Lines |
Visual Angle |
170° |
170° |
Minumum Illumination |
1 Lux/F1.2 |
1.6 Lux/F1.2 |
Waterproof Grade |
IP66 |
IP68 |
Curent Consumption |
Max 120 mA |
Max 120 mA |
Power Supply |
DC 12V |
DC 12V |
Working Temperature |
-20℃~-70℃,Max Rh95% |
-20℃~-70℃,Max Rh95% |
Storage Temperature |
-40℃~-80℃,Max Rh95% |
-40℃~-80℃,Max Rh95% |
The above parameters are for reference only.
Please refer to product specifications.
Shipping terms
Sample: 3-7 working days
Volume Order: 7-15 working days
DHL Fredex
Our Commitments:
1) Fast Service:
Pls feel free to contract us by Trade Manager or Email; All Message will be replied within 24 hours(Excludes holidays and weekend). If you do not receive our reply,please resend;
2) Competitive Price:
You could get a very competitive price,but we can not promise our price is the lowest considering the quality;We value performance price ratio more important than the lowest Price. BUY MORE, SAVE MORE! The more you buy, the lower price you will get!
3) Product quality:
We would control our products quality strictly,All items are checked and packed in good condition before delivery;It is very a effective way to reduce the percentage of products sent back for repair and save the cost for our oversea partners;
4) Fast Delivery:
Normally Samples delivered in 3-5 days, Mass production delivered in 10-20 days;
5) Warranty:
We provide one year warranty for all products, if the goods is defective, please notify us within 3 days of delivery.
Techvan Electronic Electronics Co., Ltd, Established in 2009 is hightech company which developed and manufactured auto safty electronic products such as auto camera,video reverse system.Allround view parking assist system.
Our brand “SIPAIDE”,found in 2006,one of the most popular brand of auto cameras in ,mainly engaged in universal and original car rear view camera,front view camera,side view camera,360 degree all round view parking assist system,bus&truck camera and so on.These can mix into car rear view system,front view system,side view system,bus&truck rear view system and 360 degree allround view parking assist system with DVD navigation and the vehicle displays together.The market demand is our innovative power.The rich technical precipitation and high-tech applications bring our product up to the industryleading level in technology content,technical and maintenance costs.We sincerely hope that we create a better tomorrow together by close cooperation!
1.Q: How to install it with the car for your model?
A: 1.Research and purchase the type of rear-view camera installation system that is best for your car. If you are unsure of what type would be best, you can ask for advice from the sales.
Disconnect the vehicle's battery by pulling off the negative cable. Wire the camera to the battery according to the instructions provided with your kit. The battery acts as the camera's power source.
3.Install your rear-view camera monitor. There are several possible locations to install the monitor. The most common locations are on the dashboard or sun visor. The monitor will allow you to view anything behind your car before you back out, so it should be placed in a location that is convenient when driving.
4.Use a drill to install the camera.(If you install a special camera,just move away the licence plate.) Mount the camera on the bumper, license plate, or other location at the rear of the vehicle. The kit will include all the necessary mounting hardware. Attach the camera's power wire to the back-up light power wire on your car. If you purchased a wireless camera, you do not need to wire the camera. Reconnect the car battery.
5.Test the camera before attempting to drive with it. Make sure you can clearly see what is behind the car. Turn on the camera and monitor, place an immovable object behind the car, put the car in reverse but keep your foot on the brake, and verify that you can see the object in the monitor.
2. Q: What’s the selling point of your product that is better than competitor?
A : we do very good quality products ,resonable price and good after selling service . i think that is the most important for u !
3. Q: Do you have any function in your device to protect the damage that will occur with the customer car when customer make wrong for connection wire between car and camera or car and monitor.
A : Before you install the camera, please check the use manual carefully,or check with the engineer or us.
4. Q: How should I do when the product has problem ?
A :first, you need to check the wiring methods if correct, or check the connector whether loose;
second, please connect the camera with another one monitor, just check the camera or the monitor is broken.
5. How about your guarantee policy?
A : our cameras warranty is 1.5 years ! Any quality problem can change a new one for u derectly ! Don't worry.Any problems please tell us we will deal with it ASAP.
