High Speed CNC Plasma Cut Machine G6090

Name: High Speed CNC Plasma Cut Machine G6090
Brand: Grace
SKU: 110055751
Availability: InStock

Jinan Grace Machinery Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Grace

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Grace

Model Number G6090

Rated Power 8.5kw

Weight 280KGS

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1) cutting metal
2) square orbit ,gear-wheel
3) with air cutting
4) DSP control system
5)CE certificate

High Speed CNC Plasma Cut Machine G6090

Product features:

Working Area : 600*900mm
Cutting Tickness : (ss steel) 0-6mm
Cutting Speed : 0-8000mm/min
Moving Speed :0-50000m/min
Power :8.5KW-10.5KW
Input Voltage :220V
Power Frequency :50HZ
Flies Transfer : USB Interface
Arc :Untouched Arc Striking
famous plasma power supply which with the high quality precision, more stable, and long life span.
Multifuntional software support.It can convert CAD file to program file in computer, through USB flash drive transmits to machine to realize cutting allkinds’ graphs. And also can program and operate directly on the machine.
Servo motors and step motors optional
4. Colors can choose, according to customers preferences

Application

tal cutting machine: professional metal cutting, drilling, can process on very tiny metals.

2.It can cut a lot of metal , like gold, silver , copper , iron , aluminum , steel , etc

Specifications:

Plasma Cutting Machine
Model	G6090	G1225	G1525	G1530
Power supply	USA famous brand Hypertherm power supply 45A
Voltage	220±10%VAC 50/60Hz 220W
Cutting mode	O₂
Effective cutting range(mm)	600×900	1200×2500	1500×2500	1500×3000
Track Holder Quantity	2	3	3	3
Track Holder L×W×H(mm)	500×80×40
Cutting speed(mm/min)	0-3500 (Max 4000 available)
Cutting thickness(plasma)(mm)	2-8mm (O₂)
Move precision	±0.2mm/m
Torch	electric height adjustment(±60mm)
Host weight(kg)	19
Total weight(kg)	350	630	850	950
Oxygen pressure(Mpa)	Max0.7
Emergency stop	Yes
Working temperature	-5~45°C
Relative humidity
Standard configuration is 2^#cutting nozzle if no special requirement.
Tailor-made track if request.
