Help Center12V 27W Led Resistor, Led Decoder
US$ 1 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Showjockey
Model Number:
SJ-DMX-D36PWM
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangdong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DIN Rail LED RGB DMX Decoder for RGB LED LightingUS$ 1 - 50MOQ: 1 Piece -
Factory Price DC9V-36V H1 LED HEADLIGHT Warning Canceller No Error Led Canbus Led Headlight DecoderUS$ 1 - 50MOQ: 1 Piece
-
6803/8806/2811/2801/3001/9813 Dmx IC Signal Led Pixel DMX512 Decoder 5v-24vUS$ 1 - 50MOQ: 1 Piece
-
LED Car Warning Canceller H36 Capacitor Error Free Load Resistor OBD LED Canbus Decoder for H7 Led Headlight Anti-flickerUS$ 1 - 50MOQ: 1 Piece
-
OEM China Factory LED Drl Turn Signal Light Warning Canceller,LED Turn Light Car Flashing LED Brake Light DecoderUS$ 1 - 50MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Showjockey
Model Number
SJ-DMX-D36PWM
Feature of led dmx pwm decoder:
This decoder adopts the advanced micro-computer technology and converted the DMX512 digital signal widely used in international to the analog control signal. 1~236 channels output for option and each channel able to achieve 256 gradations of controlling, and also it can be used as the connector of PC digital light controller and analog light modulator. It is mainly used for the controlling of buildings & lights applied LED.
Technical Parameters:
| Model | SJ-DMX-D36PWM |
| DMX Channel | 36 |
| Work Mode | PWM Constant Voltage |
| Gray Level | 256 |
| Speed | 1-40 |
| Frequency | 30KHz |
| Input Signal | DMX-512/1990 Standard digital signal |
| Output Signal | 0~24V,Max.5A/CH. |
| Power Supply | DC 5-24V |
| Power Dis. | 1W |
| LED Type | SMD5050,SMD3528,DIO |
| LED Color | RGB & Single & White |
| LED Fixture | LED Fixture:LED Strip,Pixel Light,Module,Matrix/Circle Panel etc |
/watch?v=7WuvG_Ao8Kw
Super cheap price with multi channel dmx pwm decoder
How to connect it with led strip to make them addressble
Installations different project in club and show
Inspection by clients and ourself check
DMX Artnet decoder work together
Meetiing with clients for different control solution
Other dmx controller work with 3D tubes lighting in club
Remote control support for client by teamviewer
Patients(DMX Controller, DMX PWM Decoder, DMX Lighting)
Certifications(CE,FCC,RoHS)
