mini phone sticker cutting laser machine G5030

Specifications

1.Taiwan brand orbits, with high precision and long life
2.CE certificate
3.USB control,
4.water pump,
5.various of tables

Desktop and mini laser machine for crafts G5030













Product features:

Working area:500x300mm

Power: 50w

Laser tube type:2500hours working life time

Control mode: USB interface

File export Software: DSP5.3

Compatible file design software: Photoshop, Corel draw, AutoCAD, etc

Files Support:: bmp, plt, eps, poes, jpg, ai, tiff, dxf, dwg, cdr, tga, jpeg, DST etc.

Mechanical orbits: Taiwan brand orbits, with high precision and long life time.

Motor and driver type: Step motors and step drivers

Cooling type: chiller.

Table type: (engraving and cutting) strip type table.

360 degree slope engrave: Support



Application:





Applicable materials: wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials



Applicable industries: advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging, paper industry





Specifications:





Laser power :	50W (optional)
Laser tube type:	CO2 glass tube
Power supply:	AC220±10, 50 HZ/ or   AC110±10, 50 HZ
Cooling way:	Water cooled with protection system
Working area:	500mmx300mm
Max travel speed:	60000mm/min
Worktable:	Honey comb worktable (mainly engraving and small pieces cutting) /aluminum knife (engraving and cutting) /normal table (engraving) (optional)
Locating precision:	<0.01mm
Min shaping character:	Character:2mm,letter:<1mm
Operating temperature:	5°C-35°C
Working humidity	5%-95%(without condensed water)
Resolution ratio:	4500dpi
Control configuration:	DSP5.3
Data transfer interface:	USB(offline)
System environment:	WINDOWS 2000/WINDOWS XP/ windows 7
Graphic format supported:	The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) etc.
Compatible software	CorelDraw, AutoCAD, Photoshop, laser cut software
Cutting thickness	0-20mm also (depends on different material)
Color separation	Separation of cutting up to 256 colors
Sloping engraving	Yes, slope can be designed discretionarily
Cuts off the water supply the protection	yes







Samples and industries application:











































Main accessories included:





1) 1*Air pump (blowing dust during work)

2) 1*Exhaust fan with Tube clips (heat radiation and smoke extraction)

3) 1*water pump (used for small power tube to cool the laser tube) or chiller (used for bigger power tube cooling)

4) 1*USB Cable (connecting PC and machine)

5) 1*CD or electronic documents (including software, user manual, guiding videos etc)

6) 2*Power cables

7) 1*Tool box (for routine maintenance)







 Other machine photos
