mini laser engraving machine G4030
- 100 Set / Sets per Month
- qingdao
- T/T Credit Card
Product Details
Condition: | New | Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood |
Cutting Thickness: | 10mm | Cutting Area: | 400x300mm | CNC or Not: | Yes |
Cooling Mode: | Water Cooling | Control Software: | READER | Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT |
Place of Origin: | Shandong, China | Brand Name: | GRACE | Model Number: | G4030 |
Certification: | CE |
Product Description
Product features:
Working area: 300x400mm
Power: 50w
Laser tube type: 2500 hours working life time
Control mode: USB interface
File export Software: Reader
Compatible file design software: Photoshop, Corel draw, AutoCAD, etc
Files Support:: bmp, plt, eps, poes, jpg, ai, tiff, dxf, dwg, cdr, tga, jpeg, DST etc.
Mechanical orbits: Taiwan brand orbits, with high precision and long life time.
Motor and driver type: Step motors and step drivers
Cooling type: water pump
Table type: (engraving and cutting) strip type table.
360 degree slope engrave: Support
Application:
Applicable materials: wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic,
glass and other nonmetal materials
Applicable industries: advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging,
paper industry
Technical Parameter:
Laser power : | 50W (optional) |
Laser type: | CO2 glass tube |
Power supply: | AC220±10, 50 HZ/ or AC110±10, 50 HZ |
Working area: | 300*400mm |
Max moving speed: | 1500mm/s |
Worktable: | Honey comb worktable (mainly engraving and small pieces cutting) /aluminum knife (engraving and cutting) /normal table (engraving) (optional) |
Locating precision: | <0.01mm |
Min shaping character: | Character:3x3mm,letter:2x2mm |
Operating temperature: | 5°C-35°C |
Working humidity | 5%-95%(without condensed water) |
Resolution ratio: | 4500dpi |
Control configuration: | DSP5.3 |
Data transfer interface: | USB(offline) |
System environment: | WINDOWS 2000/WINDOWS XP/ windows 7 |
Cooling way: | Water cooling and protection system |
Graphic format supported: | The file which CorelDraw, Photoshop, AutoCAD can identify (BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXP,PAT, CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG, SVGZ,PCT,FMV,GEM,CMX) etc. |
Compatible software | CorelDraw, AutoCAD, Photoshop, laser cut software |
Cutting thickness | 0-20mm also (depends on different material) |
Color separation | Separation of cutting up to 256 colors |
Sloping engraving | Yes, slope can be designed discretionarily |
Cuts off the water supply the protection | yes |
Whole machine dimension | 1400*750*600mm |
Gross weight | 130kgs |
packing | Plywood case (veneer wood case for export) |
Samples and industries application:
Main accessories included:
1) 1*Air pump (blowing dust during work)
2) 1*Exhaust fan with Tube clips (heat radiation and smoke extraction)
3) 1*water pump (used for small power tube to cool the laser tube) or chiller (used for bigger power tube cooling)
4) 1*USB Cable (connecting PC and machine)
5) 1*CD or electronic documents (including software, user manual, guiding videos etc)
6) 2*Power cables
7) 1*Tool box (for routine maintenance)
Packaging: Standard export wooden case or carton
Shipping: By sea or by air express
Quality warranty:
1. The laser tube of normal tube is 3 months, RECi tube is 8 months.
2. The other parts of machines are all one year.
3. Technical service is whole life time of the machine
After service:
1. To reply your question or solve problem: within 24 hours, whatever online via chatting tools like: MSN, YAHOO MESSENGER, SKYPE etc, by email or by telephone.
2. Machine will offer installation vedio, operation vedio, manual.
