Gr5 Ti-6al-4v Titanium Bar Tc4 DIN 3.7165, WL 3.7164 in Stock Baoji

Name: Gr5 Ti-6al-4v Titanium Bar Tc4 DIN 3.7165, WL 3.7164 in Stock Baoji
Brand: intlle
SKU: 110004189
Availability: InStock

US$ 25 - 30 MOQ: 10 Kilograms

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

intlle

Model Number:

D(0.8mm-350mm)*L(<8000mm)

Baoji Intelle Metals Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name intlle

Model Number D(0.8mm-350mm)*L(<8000mm)

Application Medical

Diameter 1-260MM

Shape Round

Length 3000MM

Technique Rolled

Grade GR5 Gr2 GR7

Weight 30kg

Titanium Ti-6AL-4V ASTM B348,R56400 in stock

best price titanium alloy rod for ASTM b348 Gr5 10mm diameter

i-6AL-4V GR5 titanium rods:

1.ASTM B348, ASTMF67, ASTM F136, AMS4928
2. ISO5832/2, ISO5832/3, ISO5832/11

3.dimension:dia2-350*L100-6000MM

Chemical

Application

1. Axis machining 2. the frame of the planes

3. the equipments used in the seawater

4. titanium flanges and titanium screws

5. badminton racket ,cars 6. electroplating equipment

7. conductive material 8. medical industry

9. nuclear industry 10. construction industry etc

Size(mm)	Dimensions and Tolerances(mm)	Ovality or square Tolerances(mm)
6.35~7.49	±0.13	0.2
7.49~11.11	±0.15	0.23
11.11~15.88	±0.18	0.25
15.88~22.22	±0.20	0.3
22.22~25.4	±0.23	0.33
25.4~28.58	±0.25	0.38
28.58~31.75	±0.28	0.41
31.75~34.92	±0.30	0.46
34.92~38.1	±0.36	0.53
38.1~50.8	±0.40	0.58
50.8~63.5	±0.79	0.58
63.5~88.9	±1.19	0.89
88.9~114.3	±1.59	1.17
