TG230 Inflatable Boat High Pressure Air Pump
Appalication of TG230 Inflatable Boat High Pressure Air Pump
-Air compressor widely used in makeup airbrush.
-Air compressor widely used in nail art airbrush.
-Air compressor widely used in model painting airbrush.
-Air compressor widely used in tattoo airbrush.
-Air compressor widely used in cake decorating airbrush.
-Air compressor widely used in hobbies & crafts airbrush.
Discriotion & Feature of TG230 Inflatable Boat High Pressure Air Pump
Feature:
1, Double cylinders and output flow is big, can drive several airbrush guns to work
2.Air output pressure can be adjusted ,with pressure gauge and the oil-water separator
3, piston type, oil free,non-pollution;
4, With 2 level air pressure switch:
First level: low-voltage automatic stop switch, suitable for low pressure tools like airbrush;
Second level: high pressure non stop switch, suitable for other pneumatic tools which need need high pressure;
5.can work continuously, and can start under pressure, powerful
5, motor has overheating protection device;
7, noise: 47 db;
8, with automatic startup and automatic stop function;
9.Air tank with safety protection device
Certification: ROHS, CE, GS, ETL and CETL
Compressor Type:TG230( double cylinder piston compressor )
1.Power: 1/4HP
2.Voltage: 220-240V/50HZ 110-120V,220V/60HZ
3.Auto stop: start at 3BAR/43PSI, stop at 4BAR 57PSI
4.Max pressure: 6BAR/86PSI
5.air output per min.: 30-35L/min.
6.Conector: 1/8" BSP
7.electric cable:1.5m
8.weight: 5kg
9.Dim: 320×135×205mm
TG230 Twin Cylinder Airbrush Compressor kit Package Information
Weight: 5kg
Dim: 320x135x205mm
Carton
inner carton size(CM):34.5*16*21.5
Dimensions(CM):66x36x23.5
PCS/CTN: 4
N.W./G.W.:20KG/22.7KG
Pictures of TG230 Inflatable Boat High Pressure Air Pump
------------------------------------------------------------------------------------------------------------------------------
Pls see several of our hot items as below, if you couldn't fine what you want here, that's ok, pls let me know your requests, we can custom perfectly and promptly.
| type: TG218 single cylinder piston compressor 1.power:1/8HP 2.voltage:220-240/50HZ 110-120V, 220V/60HZ 3.air output per min./litres:20-23L/MIN nnections:1/8"BSP 5.electric cable:1.5m 6.auto stop: satrt at 2.1BAR, stop at 3.1BAR |
| | type: TG212B single cylinder piston compressor 1.power:1/6HP 2.voltage:220-240/50HZ 110-120V, 220V/60HZ 3.air output per min./litres:20-23L/MIN nnections:1/8"BSP 5.electric cable:1.5m 6.Auto stop: start at 3BAR/43PSI, stop at 4BAR 57PSI 8. Size: 255*135*205MM |
| | Type: TG230 double cylinder piston compressor 1.Power: 1/4HP 2.Voltage: 220-240V/50HZ 110-120V,220V/60HZ 3.Auto stop: start at 3BAR/43PSI, stop at 4BAR 57PSI 5.air output per min.: 30-35L/min. 6.Conector: 1/8" BSP 9.Dim: 320×135×205mm
|
| | Type: TG212T single cylinder piston compressor with tank 1.Power: 1/6 HP 2.Voltage: 220-240V/50HZ 110-120V,220V/60HZ 3.Auto stop: start at 3BAR/43PSI, stop at 4BAR 57PSI 4.air output per min.: 23L/min. 5.Conector: 1/8" BSP |
| Type: TG230TC double cylinder piston compressor with tank and protection cover 1.Power: 1/4HP 2.Voltage: 220-240V/50HZ 110-120V,220V/60HZ 3.Auto stop: start at 3BAR/43PSI, stop at 4BAR 57PSI 5.air output per min.: 30-35L/min. 6.Conector: 1/8" BSP |
| Type:TG216S compressor 1. Voltage: DC12V 50Hz/60Hz |
| | Type:TG216 compressor 1. Voltage: DC12V 50Hz/60Hz |
More relative product picture
----------------------------------------------------------------------------------------------------
-Compressor Maintance
-Cleaning the compressor after every use.
-After every use,drain the water collected in the filter/regulator bowl,pressing upwards the valve placed on the bottom side of the cup(outlet must be pressurized).
-Once every three months ,clean the filter of the the filter/regulator by blowing with compressor air.
-----------------------------------------------------------------------------------------------------------------------
1.About Sample:How could I get a sample?
We have to receive your payment for samples and their express delivery cost, then send samples to you.
The prices of the samples are the same on the pricelist.
Express delivery charge depends on the quantity of the samples.
2. About Price: Could I get your price list?
Yes, please tell us the products(with their model number), quantity you are interested in, then we will offer the price by e-mail.
3.About Shipment: What kind of shipment will you use?
We usually ship the products by sea via our shipping agent.Express, we can ship the products to any place of the world.
4.About OEM: Could we place order by OEM style to produce our own brand products in your factory?
Of course you can. Welcome to do OEM. What you need to do is email us the brand name or logo.
----------------------------------------------------------------------------------------
For more choice and detailed specification. Pls visit our website or http://cntaiger.en.china.cn/ and download our E-caralogue. If any question, pls feel free to contact us! We will reply you immediately!
