High precision and factory price SD-1390 laser engraving cutting machine with CE
We also have many different working size, such as 1200*900mm, 400*400mm,600*900mm, 1300*2500mm,1400*900mm, 500*300mm, 1600*2500mm etc. And we can manufacture machines that can meet the customers' requirements.
SD Laser --- Advantages and service we supply
J Excellent and High Quality Control
JInnovative spirit, ideas and consciousness
JBest after-sale service
JCustomer's Designs and Logos are Welcome
JCompetitive Price
JEarth-friendly Product
JPrompt Delivery
Features:
1.Equipped with high precision ball screw uo-down working table.
2.High speed USB offline control system.
3.The compatibility of the software is good, which can support Photoshop, Auto CAD, and CorelDraw.
4.The data control is stable. Adopted imported linear guide, more stable and higher accuracy.
5.Choose high technical laser tube, the beam of light is of high quality and the life is long.
6.Cofigurate the industrial water cooling system with protection, the continuous work ability is stable.
Technical parameters:
Laser type |
Sealed CO2 laser tube |
Laser power |
60W,80W,100W,130W,150W,200W (optional) |
Engraving area |
1300×900mm |
Engraving speed |
0-60,000mm/min |
Resetting position accuracy |
±0.01mm |
Working voltage |
AC110-220V ±10%.50-60HZ |
Power |
<1,000W |
Operating temperature |
0-45°C |
Operating humidity |
5-95% |
Minimum shaping character |
English 1×1mm |
Graphic format supported |
BMP, PLT,DST, DXF,and AI |
Driving system |
Stepper |
Cooling mode |
Water-cooling and protection system |
Auxiliary equipment |
Exhaust-fan, air-exhaust pipe |
Controlling software |
DSP control system |
Compatible software |
Coreldraw auto CAD photoshop |
Applicable Industry:
1.Engraving beautiful patterns and words such as wood, bamboo, Ivory, bone, leather, marble,
shell.
2.Mainly used in large plastic character cutting, color plate engraving, organic glass engraving and
cutting, sign engraving, crystal engraving, trophy engraving, authorization engraving, etc.
3.Leather Clothing Processing Industry: Can engraving and cutting complex patterns on genuine
leather, synthetic leather, leather, woolens, clothing, furnishings, glove, handbag, shoes, hats,
toys, etc.
4.Model Industry: Production of construction sand table model and Aircraft Model, etc. ABC plate
cutting, MLB cutting.
5.Packing Industry: Engraving and printing rubber plate, plastic plate, double board, die cut plate.
6.Other Industry: Engrave on marble, granite, glass, crystal and other decorative materials,
cut paper, card.
7.Product Identification Industry: Security marking products, etc.
What should NOT be cut by the laser?
While the laser can cut or engrave, some materials should not be CUT. Vinyl and PVC will produce a corrosive gas. Plexiglass / Polycarbonate will produce a black and yellow gas that will make your sick to your stomach. Cutting ABS yields a fair result, but leaves a bad smell that is hard to get out of your nose.
optional parts
Sample
Warranty and service:
1.12 Months for Machine. 2.6 Months for laser tube, lens and mirror. 3.6 Months for equipments outside, such as water pump, fan, air pump,etc. 4.Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material. 5.Lifely and fast technical guide and solution within 24hours by email and web camera.
Jinan Shendiao Machinery Equipment Co., Ltd is the professional manufacturer and exporter of mechanical CNC router machine, laser machine and other relevant equipment. Our products are widely used in various industries. We have granted our own brand "Shendiao" or "SD". By reason of high quality products and top after-sales service, we have won trust and support of customers from all over the world.
Frequently asked questions
1. How can I get order a Shendiao machine?
Please contact me via email, telephone, fax, MSN, Yahoo messenger, Skype and so on.
2. What is the lead time for a Shendiao machine?
For regular model it is app. 2 weeks, for custom-built model, it need more days.
3. What are the acceptable payment methods?
When purchasing directly from Shendiao (this may differ if you purchase from one of our distributors), you can make the payment via bank wire transfer, Western Union or Letter of Credit (L/C).
4. What is included in the price of the machine?
Laser engraver/cutter – Standard external spares and cables – Software – Operational manual – 1 year warranty. (Necessary spares to run machine).
5. What is not included in the price?
PC – Coreldraw software – AutoCad software
6. What is the warranty for Shendiao machines?
All Shendiao laser engravers/cutters are covered by a 1-year warranty (EXW, ex-works China).
7. Is the set-up complicated? Will I need a professional installer?
No. All our models come with step-by-step assembly manuals and can be assembled within 2 hours (depending on the model) by anyone with basic manual skills. The operation manual will help you start on the same day when you set up machine. Although not necessary, installation and training can also be performed by a Shendiao technician at an additional charge.
8. Whom do I contact for technical support?
You can contact us no matter what the problem is, just send us an email or give us a call and we will do all we can to solve the problem asap. When sending an email with a technical question or a drawing problem, please make sure to include as much information as possible: info on the machine, software version, serial number, installation date, your PI No., your location, etc.
9. What should NOT be cut by the laser?
While the laser can cut or engrave, some materials should not be CUT. Vinyl and PVC will produce a corrosive gas. Plexi-glass / Polycarbonate will produce a black and yellow gas that will make your sick to your stomach. Cutting ABS yields a fair result, but leaves a bad smell that is hard to get out of your nose.
10.What industries would benefit from the use of a laser engraver?
Sign makers, party decorations, novelty makers, awards and trophies, applique embroidery, wooden toys, airplane models, model buildings, textile patterns, template makers, etc.
Contact info
Contact person:Janny lei
Mobile phone:+86 15216401275
Tel: 0086-531-88084966
Fax:0086-531-88084966
Working hours:8:30am ~ 17:30pm at Beijing time (Mon ~ Sat)
Website:
Welcome to our company personally,we are very appreciated it if you are interested in our products.
Please contact us at your convenience.Thank you very much for your reply.
