Specifications
Stainless Steel Laser Cutting Machine1.Mechanicial Follow-up Cutting Head
2.Cut metal and non-metal
3.Manufacturer CE
Stainless Steel Laser Cutting Machine
Feature:
1. Big Working Area -- Suit to 900 X 1300mm size material cutting.
2. Non-Contact Auto Focus System -- Provide easy & convenient auto focus laser beam.
3. Mechanical follow-up laser cutting head-- automatically adjust the certain focus distance .
4. Modularize Design -- Enable maintenance faster & easily.
5. Lens Socket Design -- Convenient to exchange and maintain lens 2.5", 4.0"
6. Three Sloping Hopper Design -- Collect the cutting work pieces conveniently.
7. Smooth Feeding Design -- Make material sheet feeding easily.
8. Invisible Upper Exhaust -- Create simple & effective upper exhaust system.
9. Sealed Laser Optic Path -- Ensure operating safety.
10. Imported Lens and Mirror -- HIgh effeciency and precision of cutting.
11. Collecting Drawer -- Make product collection easily.
12. Laser Software (Option) -- provides special functions to make excellent product rapidly
Specification:
SD-1390 |
|
|
Wattage |
|
150W/180W |
Laser Source |
|
Sealed CO2 Laser |
Cooling |
|
Water Cooled |
Working Area |
|
900*1300mm |
Dimensions (W x L x H) |
|
1160Tall x 1360Deep x 1860Wide mm |
Drive |
|
stepper or Servo control |
Maximum Motor Speed |
|
40 IPS |
Speed Control |
|
Adjustable from 0~100% |
Power Control |
|
Adjustable from 0~100% |
Distance Accuracy |
|
0.1mm |
Z-Axis Movement |
|
Automatic or manual |
Computer Interface |
|
Standard printer port and USB 2.0** port |
Operation Voltage |
|
110V-220V AC |
Power Consumption |
|
2300w |
Graphic format supported |
|
BMP,JPG,GIF,HPGL,NC,PLT,DST,DXF,AI ... |
Water Chiller |
|
Water Chiller required |
Air Exhaust System |
|
External exhaust system required |
Configuration:
The parameters of cutting ( Just for reference), 150W
Material |
Cutting thickness |
Cutting speed(mm/min) |
Stainless steel |
0.5mm |
2700 |
1mm |
1800 |
|
1.5mm |
1000-1200 |
|
Carbon steel |
0.5mm |
3000 |
1mm |
1800 |
|
1.5mm |
1000-1200 |
|
Acrylic |
10mm |
300 |
20mm |
90-120 |
|
MDF |
10mm |
300-400 |
Cutting and Engraving materials:
Stainless steel, Mid-steel, Bamboo, jade, marble, glass, crystal, plastic, garments, paperleather, rubber, ceramic, Hard Wood, MDF, Plywood, Plexiglas, Plastic, Acrylic, and othe non metal materials.
Applications of Laser machines :
Advertising, arts and crafts, leather, toys, garments, model, embroidery, clipping, packaging and paper industry, Wood Working, engraving embroidery, crafts, RC airplanes, balsa models, kites, robotics kits, and clothing patterns
Jinan Shendiao Mechanical Equipment Co.,Ltd is known for excellent service and bringing forth laser products that are the best quality of all Chinese laser cutting machines. This equipment can be applied to many kinds of materials, and has many advantages, such as smooth cutting edges, free from polishing, no noise, no dust, faster processing speed, higher precision, less waste and more efficiency. It is the best option for upgrading traditional equipment in various industries.
If custom ordering a machine, the color can also be specified.
1. Free consultation service before, during, and after sales;
2. Free project planning and design services;
3. Provide 1 year complete warrantee and life-time maintenance service;
4. Installation/Operation/ Service/ Maintenance Manual and Video: Provided In English
