2015 Best Style Top Supplier CO2 Laser fabric and crystal and wood laser cutting machine with CE
We also have many different working size, such as 1300*2500mm, 400*400mm,600*900mm, 1300*900mm,1400*900mm, 500*300mm, 1600*2500mm etc. And we can manufacture machines that can meet the customers' requirements.
Features as below:
1. Configure higher power laser tube.
2. DSP controlling system, rich functions.
3. Owns functions of restoring from power off, continuation on break point.
4. Transmit files directly in CorelDraw, AutoCAD etc.
5. Adopt international linear rail, more precision.
Specifications:
Model |
SD-D1290 |
||
Standard Laser power: |
80w/80w |
||
Optional Laser power: |
60w, 100w, 120w, 130w |
||
Engraving Area(mm) |
1200x900 |
||
Gross power |
1600w |
||
Laser type: |
CO2 Laser tube |
||
Cutting depth: |
Acryl 0-40mm, others material(varied according to the nature) |
||
Engraving speed : |
0-1000mm/s |
||
Cutting speed: |
0-600mm/s |
||
Resetting positioning accuracy: |
<0.01mm |
||
Maximum forming character: |
Figure/English: 1x 1mm |
||
Power supply: |
220V±10% 50HZ or 110V±10% 60HZ |
||
Software supported: |
ArtCut, PhotoShop (Conversion output) CorelDraw, AutoCAD, Lasercut (Direct output) |
||
Main Graphic format supported: |
PLT/DXF/BMP/AI (Direct output) |
||
Water Cooling: |
Yes |
||
Laser tube(life hours): |
3000-4000 hours |
||
Certificate |
CE |
||
Assistant Equipment: |
Dual red dot pointer |
Water pump |
Air pump |
Optional Spare Parts: |
Motorized table |
Water chiller |
|
Spare Parts Recommend (R): Laser Tube, Lens, Mirror | |||
Optional water cooling:
Unique Accessories Included:
Two laser heads: The two heads can move at the same time, which will save space compare with two sets machines. Software included: LASERCUT (Support Coreldraw, AutoCAD direct output)
Application Field:
Nonmetal materials such as stone, marble, granite, gravestone, tombstone, acrylic, glass, ceramics, wood, bamboo. Double colored boards, paper, leather. etc.
Applicable Industries:
Model Industry(construction models, aviation and navigetion models and wooden toys), advertisement, decoration, art crafts, electronics, and electric appliances, etc.
What should NOT be cut by the laser?
While the laser can cut or engrave, some materials should not be CUT. Vinyl and PVC will produce a corrosive gas. Plexiglass / Polycarbonate will produce a black and yellow gas that will make your sick to your stomach. Cutting ABS yields a fair result, but leaves a bad smell that is hard to get out of your nose.
Samples show:
Our Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
Warranty and service:
1.12 Months for Machine.
2. 6 Months for laser tube, lens and mirror.
3. 6 Months for equipments outside, such as water pump, fan, air pump,etc.
4. Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material.
5. Lifely and fast technical guide and solution within 24hours by email and web camera.
Jinan Shendiao Machinery Equipment Co., Ltd is the professional manufacturer and exporter of mechanical CNC router machine, laser machine and other relevant equipment. Our products are widely used in various industries. We have granted our own brand "Shendiao" or "SD". By reason of high quality products and top after-sales service, we have won trust and support of customers from all over the world.
Our price is very competitive, because we are the factory and the source.
Q:If our price is higher than other company or factory?
A:plaese check, what is is the different of the machine parts ,service and guarantee belive you will chooes the same value of the machine, not cheaper equipement.
Q.How long is the delivery time?
A.For standard machines, it would be 7-10 days;
For nonstandard machines and customized machines according to clients specific requirements, it
would be 15 to 30 days.
Q:What’s the guarantee?
A:1.Laser tube guarantees 12 months. While the whole machine guarantee for 1 year.
2.24 hour’s technical support by email or calling.
3.English manual and video tutorial.
4.one year quality guaranty for the machine (excluding the consumables).
5.Lifetime maintenance free of charge.
6.We will provide the consumable parts at an agency price.
7.12 hours on line service each day, free technical support.
