3.5" LCD Inspection 8.2mm Camera with 1m/3m/5m Flexible Supporting Cable

Brief Description



This Large 3.5" Color LCD Video Inspection Camera uses optoelectronic technology to investigate hard-to-reach areas. Compared with traditional inspection camera, the built-in 1W LED flash light by well-known manufacturer CREE  provides a powerful light source to the surroundings which enables you  to work in dark areas much more conveniently and easily. In addition,  the camera head equips 6 pcs of adjustable high-intensity LEDs (with brightness control) to illuminate the inspection areas specifically.



The LCD receiver can be detached from the main unit for remote viewing up to 1.5 meters (4.95 feets) away with the connecting cable. It supports 4X zoom and 360° image rotation & flip over. You can capture images (JPG) up to 3 megapixels or videos (AVI) up to 720p HD. You can conveniently save your data in MicroSD card or output to TV and PC by Video Out and USB interface respectively.



The 1 m / 3m / 5m flexible tube with slim 8.2 mm camera head is waterproof  so that you can inspect areas under water, gaps and holes especially  with small openings. Ergonomic and robust designs of this product are  including one-hand operation, multi-language menu, adjustable handle  angle, and stainless steel shield.



This inspection camera helps you to diagnose broken part, weld point  and released parts easily to save time and increase productivity. It  has many applications including HVAC inspection, vent pipe, machine  equipment, engine, cable routing, automotive / boat / aircraft  inspection, etc.





Features

  • Capable to investigate dark and hard-to-reach areas
    •
  • Built-in 1W LED flash light by CREE
    •
  • Large 3.5" color LCD monitor with high resolution and visibility
    •
  • Detachable LCD receiver for remote viewing with cable
    •
  • 4X zoom and 360° image rotation & flip over
    •
  • Capture images (JPG) up to 3 megapixels or videos (AVI) up to 720p HD
    •
  • Menu in 7 languages
    •
  • IP67 waterproof probe and camera head
    •
  • Slim 8.2 mm camera head with 6 pcs of adjustable LEDs
    •
  • MicroSD slot, Video Out, USB interface
    •
  • Accessories including hook and magnetic tips
    •
  • Ergonomic and robust designs
    •
  • Flexible, portable, easy to operate and stable performance
    •
  • Ideal for industrial such as automotive, electrical, plumbing,  heating, ventilation, air conditioning, refrigeration and general home  inspection, building and home construction, aviation, vehicles  maintenance





Specifications

  • Light Source: 1W LED flash light
    •
  • Display: 3.5" color LCD with 320×240 pixels resolution
    •
  • Video Resolution: 320x240 / 640x480 / 1280x720
    •
  • Image Resolution: 640x480 / 1600x1200 / 2048x1536
    •
  • Menu Language: English, Chinese, French, German, Spanish, Russian and  Japanese
    •
  • Data Storage Media: 2GB MicroSD card included (supports up to 32GB)
    •
  • Camera Head: 8.2 mm diameter with 6 pcs of adjustable LEDs
    •
  • Viewing Angle: 60°
    •
  • Depth of Field: 80mm ~ infinity
    •
  • Probe Length:  1 m / 3m / 5m
  • Probe and Camera Head Protection: IP67
    •
  • Operating Temperature: 0 ~ 45 °C (32 ~ 113 °F)
    •
  • Power Source: 4 x AA batteries (not included)
    •
  • Max Battery Life: 4 ~ 5 hours
    •
  • Dimension (Grip): 260 (L) x 95 (W) x 80 (H) mm (excluding the probe)
    •
  • Weight: 445 g (excluding the probe)





One Set Included

  • 1 x Inspection Camera
    •
  • 1 x 3.5 inch LCD Receiver (detachable from Camera Grip)
    •
  • 1 x  1 m / 3m / 5m Probe with Waterproof Camera Head
    •
  • 1 x Magnet Tip
    •
  • 1 x Hook Tip
    •
  • 1 x Remote Connecting Cable
    •
  • 1 x USB Cable
    •
  • 1 x Video Cable
    •
  • 1 x 2GB MicroSD Card
    •
  • 1 x MicroSD to SD Card Adapter
    •
  • 1 x Instruction Manual
    •
  • Standard Factory Package
