1. Application for Temperature Humidity Climate Chamber
The programmable temperature humidity test chamber is applied to test the capabilities of heat-resistance, cold-resistance of materials.It's mainly used in testing the adaptability of electronics,
electrical appliances,food,automobile,rubber and plastic,metal and other materials or finished products,components in the high and low temperature environment when storage,transport and using.You can select from a variety of sizes,ranges,and options to meet your specific testing requirements.
2.Features for Temperature Humidity Climate Chamber
> Stainless steel 304# 1.2mm exterior
> Energy-efficient refrigeration with exclusive electronic expansion valve system
> Specialized humidity generation and control
> Unique thermal break construction for extreme testing
> 3" cable port,two shelf & casters included
> 5.5" Imported TAIWAN brand " DELTA" touch screen
>. USB port and WLAN port can be added for machine(can be customized).
3. Corresponding Standard for Temperature Humidity Climate Chamber
> IEC60068-2-1.1990 Low Temperature testing method
> IEC60068-2-2.1974 High-temperature testing methods
> GJB150.3 High Temperature testing method
> GJB150.4 Low temperature testing method
> GB11158 Technical conditions for high-temperature testing box
> GB10589-89 Technical conditions for Low temperature testing box
> GB/T2423.1-2001 Low temperature testing methods
>GB/T2423.2-2001 High-temperature testing methods
> GB/T2423.22-2001 Temperature testing method
10. GB10592-89 Technical conditions for high and low temperature testing box
4. Technicial Parameters for Temperature Humidity Climate Chamber
| Model | MHU-100 | MHU-150 | MHU-225 | ||
| Interior Dimension (cm) | 50×50×40(100L) | 50×60×50(150L) | 50×60×75(225L) | ||
| Overall Dimension (cm) | 88×84×148 | 102×100×172 | 101×110×194 | ||
| Machine weight(kg) | 200 | 250 | 320 | ||
| Model | MHU-408 | MHU-800 | MHU-1000 | ||
| Interior Dimension (cm) | 600×85×80(408L) | 80×100×100(800L) | 100×100×100(1000L) | ||
| Overall Dimension (cm) | 121×114×196 | 128×148×203 | 148×148×203 | ||
| Machine weight(kg) | 400 | 500 | 600 | ||
| Parameter | Temp. range | Model S:-70°C~+150°C ,Model L: -40°C~+150°C | |||
| Humidity Range | 20% ~ 98% R.H | ||||
| Humidity bias | +2~-3%R.H | ||||
| Temp. fluctuation | ≤±0.5°C | ||||
| Temp. uniformity | ≤2°C | ||||
| Cooling rate | 0.7-1°C/min | ||||
| Heating rate | 1.0-3.5°C/min | ||||
| Material | Chamber body | High-quality SUS304 stainless steel /1.2mm thickness | |||
| Shell material | High-quality SUS304 stainless steel /1.2mm thickness | ||||
| Liner material | High-quality SUS304 stainless steel /1.2mm thickness | ||||
| Insulation materials | Ultra-fine glass fiber insulation cotton / rigid polyurethane foam | ||||
| Door seal |
Double resistance to high and low temperature aging and hardening of refined silicone seal |
||||
| Cooling model | Air cooled or water cooled for choose. | ||||
| Compressor |
French Tecumseh(imported from Frence) -40℃ chamber with one compressor, -70℃ chamber with two stage compressor |
||||
|
Controller (Imported from TW, TATO brand) |
-Imported from TW DELTA 7" controller or tranditional Korean TEMI880 5.5"controller for choose. -99 program x 99segment and 100H/ segment setting capacity (each segment means specific temperature,humidity and test time)999cycles circulation setting,and enclose multiple sets of PID control function and RS232 PC connection interface control. -Accuracy range: temperature ± 0.1 °C, indicating accuracy: temperature ± 0.1 °C, resolution: ± 0.1 °C - Available in English and Chinese,LCD touch screen control. -Create or copy programs -Upload and download programs via USB -Copy,edit,insert,and delete steps -Two nested loops repeat up to 999 times -Selectable end-of -test modes -Create pause steps within programs -Soak control delays timer until setpoint is reached Additional Functions - Alarm report details last 1000 alarms -Time signal relay control(with naming capability) -High/Low limit alarm functions -Audible alarm with on-screen help -Selectable restart modes after power failure -Auto start and stop functions -Keylock protection and configuration lock-out -Service guide and help screens |
||||
| Humidification | External isolated, stainless steel electric steam humidification mode occurs | ||||
| Dehumidification |
Condensation method using the dew point temperature of the evaporator coil dehumidification mode laminar contacts |
||||
| Security Devices |
Power overload, leakage, grounding, over-temperature protection (with voice prompts), fast fuse, compressor over-voltage protection, buzzer alarm,compressor thermal protection |
||||
| Resistant to high and low temperature heat tempered glass hollow glass windows: | |||||
| Power supply | AC220V±10%,50/60HZ or 380V±10% ,50/60Hz, 5KW | ||||
5. Control Interface of Temperature Humidity Climate Chamber
6. CE certificate of Temperature Humidity Climate Chamber
Dongguan Jianqiao Testing Equipment Co.,Ltd. is a China base manufacturer and exporter of testing equipment. It is a high-tech company in metal and non-mental materials testing,measuring,and analytic industries. We are specialized in R&D,production,focus more on quality and after-sales service.
We always try our best to devote ourself in providing high quality products which based on our innovation,exellent technoligy team,and strict production control system.
Our Products
ISO 9001 Certificate
1.Pre-service
24 Hours online service for your consult
Help choose right model with series of service,person, and adviece
2.Middle service
--Give you best offer
--Provide favourable discount
--Meet your demand
--Choose payment term you convienent
--Promptly production and delivery, inform you in time
--Provide invoice value as you like to decrease your tax
3.After-sale service
--1-year warranty service
--Technical Egineer are avalible for oversea trainning
--Free change for some parts
--Remote control technical consult
--Maintenance plan
4.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
