Help Center400kg/h SJSZ80 Pvc Compounding Pelletizing Machine
Related Products
-
SJSZ Series PVC Pellet Production MachineUS$ 46,600 - 47,500MOQ: 1 Set -
Wasted PP PE Film Pelletizing LineUS$ 13,500 - 58,000MOQ: 1 Set
-
PET Bottle Flake Recycling LineUS$ 50,000 - 86,000MOQ: 1 Set
-
Professional Carbonated Drinks Filling Line A-Z SolutionUS$ 9,000 - 70,000MOQ: 1 Set
-
Automatic Bottle Leak TesterUS$ 5,600 - 6,000MOQ: 1 Set
Specifications
pvc compounding pelletizing machine1. capacity:400kg/h
2. consist of SJSZ80 extruder,cutting mold, cutter,silo.
3. CE
400kg/h pvc compounding pelletizing machine
Application of PVC pelletizing machine:
With different designs of screw, this machine can be applied to granulate the recycled material of rigid PVC, soft PVC and waste PVC. It can be stopless in the course of production.It used pneumatic conversion and strong-wind blowing. At the same time can adjust stainless steel storage container and can run at high speed for a long time while extrude stably.
Features of product:
1.advanced equipment, precise pelletizing and high producing capacity.
2. Conical double-screw extruder, very suitable to process PVC powder with high capacity
3. Pelletizing style: Hot-cutting on mould face, even cutting ensures good shape.
4. Auxiliary machine: Pellets cooling & classifying.
Process flow:
Raw material+ additive → Mixing → Conveying feeding → Force feeding → Conical twin screw extruder → Blowing hot-cutting mould → Cyclone separator → Vibrating screener → Blowing system → Storage hopper → Finished product packing
Technical parameters:
Model |
screw diameter (mm) |
L/D |
Capacity (kg/h) |
Main motor power(kw) |
Total power (kw) |
Line length (m) |
SJZ51 |
51/105 |
14.5:1 |
120 |
18.5 |
70 |
12 |
SJZ65 |
65/132 |
14.6:1 |
200 |
37 |
100 |
14 |
SJZ80 |
80/156 |
15.25:1 |
350 |
55 |
150 |
16 |
SJZ92 |
92/188 |
17.86:1 |
600 |
90 |
200 |
18 |
