Specifications
variable speed centrifuge1.1 year warranty
2.wholesale price,fast delivery
3.LCD display;Brushless converter motor
4.CE&ISO
TGL20M Lab refrigerated variable speed centrifuge
Features:
- Microprocessor control, operated by touch panel, LCD display, operating data can be saved automatically, RCF value can be set directly for working, easy to use.
- Brushless converter motor which has high torque, high speed bearing from European that running smoothly and maintenance-free
- Freon-free compressor, fast cooling, low noise and slight vibration, green.
- Steel body, stainless steel centrifugal chamber, imported of key components with high quality, durable and easy to clean
- overspeed, overtemperature, door interlock, unbalance protection function, the rotor can be disinfected at high temperature and high pressure to ensure safety.
Techinical parameter :
Model |
TGL20M |
Maximum RPM |
20500r/min |
Maximum RCF |
29200 x g |
Maximum Capacity |
400ml |
Temperature Range |
-20°C - +40°C |
Time Range |
0-99min |
Speed Accuracy |
±50r/min |
Temperature Accuracy |
±1°C |
Noise |
≤65dB |
Power supply |
AC220V, 50Hz,18A |
Dimension |
650 x 580 x 370 mm |
Net Weight |
95 kg |
Rotor options
Rotor Type |
Rotor No. |
Capacity (ml) |
Max Speed (r/min) |
Max RCF (xg) |
Dimension of tube (mm) |
Angle rotor |
6 |
12x 1.5/2.0ml |
20500 |
29200 |
Φ10x42 |
9 |
24x 1.5/2.0ml |
16000 |
23200 |
Φ10x42 |
|
12 |
10x5ml |
16000 |
17420 |
Φ14x54 |
|
16 |
12x10ml |
15000 |
23120 |
Φ16x81 |
|
18 |
48x0.5ml |
13000 |
14740 |
Φ8x32 |
|
22 |
6x50ml |
13000 |
17380 |
Φ28x105 |
|
31 |
4x100ml |
10000 |
9690 |
Φ38x124 |
|
88 |
4x10ml |
4000 |
1431 |
Φ18x85 |
|
Microplate rotor |
44 |
2x48 holes |
3000 |
1400 |
Microplate |
Remarks: If you have any request of the centrifuge, please feel free to let us know. Your request will always draw our first attention.
Product photos :
non-return valve for centrifuge
axle bearing for centrifuge
control pannel for centrifuge
In 2008 the program in China for aid to Cuba, Kaida is the only one centrifuge supplier in this program and sold 102 sets of DL6M to Cuba blood center.
packing&delivery
