DL5M-II Low speed Refrigerated centrifugal machine

Specifications

Low speed Refrigerated centrifugal machine
1.swing rotor
2.brushless motor
3.LED Display
4.can set RPM,RCF,time,Temperature

DL5M-II Low speed Refrigerated centrifugal machine



Features:

1. Microprocessor control, operated by touch panel, LCD display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2.Brushless converter motor which has high torque, Bearing from Europe, smoothly running and maintenance-free.
3.Multistage damping system, the freon-free compressor from Europe, low noise and slight vibration,green.
4.Steel body, stainless steel centrifugal chamber, imports of key components, durable and easy to clean.
5.overspeed, overtemperature, door interlock, unbalanced protection, ensure safety.
6.Built-in Chamber pre-cooling system, makes temperature fast cool down. Proprietary SCT speed control technology, save time and high efficiency.
7. Super SBT meet special requirements such as medical, cell separation, is widely used in the field of radicalization immunity, biochemistry, pharmacy and so on.



Technical Parameter:



Model	DL5M
Max Speed	5000r/min
Max RCF	4390* g
Max Capacity	1000ml
Speed Accuracy	±50r/min
Temperature Range	-20°C to +40°C
Temperature Accuracy	±1°C
Time Range	0-99min
Power Supply	AC 220V 50Hz 20A
Noise	≤ 65dB
Dimension	590*510*780mm
Weight	130kg



Rotor:

Model	Number	Capacity	Max speed (r/min)	Max RCF(×g)	Dimension of tube (mm)
Swing Rotor	No.63	4×50/100ml	5000	4390	Φ38x124
	No.70	4×250ml	4000	3500	Φ64x112
	No.81	8×50/100ml	4000	2810	Φ16x114-118
	No.85	96×7ml	4000	2800	Immuno Tube
	No.85	80x7ml	4000	2800	Vacuum blood collection tube



Remarks:

If you have any question or special requirement about this product, please feel free to contact us. Your request will always draw our first attention.
