Help Center7 Inch Slew Drive for Inclined Single Photovoltaic Tracking Station
Related Products
-
3 Inch Dual Slew Drive for Solar Tracking SystemUS$ 200 - 1,000MOQ: 1 Set -
5 Inch Dual Slew Drive for Solar Tracking SystemUS$ 200 - 1,000MOQ: 1 Set
-
DA7 Solar Tracking Slew DriveUS$ 200 - 1,000MOQ: 1 Piece
-
7 Inch Slewing Drive for Solar Tracking System Slew Worm DriveUS$ 200 - 1,000MOQ: 1 Piece
-
TItanhorse 7 Inch Dual Axis Slew Worm DriveUS$ 200 - 1,000MOQ: 1 Piece
TITANHORSE Slewing Drive:
1. Own ring forging plant, gurantee your orders delivery on time with lower cost.
2. 5S whorkshop management, ISO standard, make sure all the slewing drives exported with high quantity.
We have 3'', 5'', 7'', 9'' even 21'' five sizes dual axis slewing drive, and 3''-25'' nine sizes single axis slewing drive.
Call or email me today, let me select the right slewing drive for you.
Enclosed slewing drives are the most popular model of Titanhorse’ slewing drives and can help power movement in machinery such as wind turbines, military equipment, digger derricks, solar trackers, medical equipment, forestry, waste management and industrial positioners. The housing fully encapsulates all the drive components such as the double enveloping worm gearset, planetary gearing, and turntable bearing, such that they have total protection from the elements. The Enclosed Drive is also advantageous if you’re mounting inside so as not to see the parts in motion, or to avoid injuring workers working in close proximity.
Slewing drives are ideal for jobs that require both load-holding and rotational torque from the same gearbox. The fully-enclosed comes with Titahorse’ patented hourglass worm technology, or cone drives and double enveloping worm gearsets where required, for maximum load-holding and efficiency. Each size is rigorously tested for reliable performance, with base model sizes producing 6kNm to 2200kNm of holding torque, 200Nm to 630kNm of output torque, 500Nm to 2710kNm of overturning moment load capacity, and gearbox reduction ratios of 30:1 up to 156,600:1.
Introduction
Slewing drive is consist of slewing bearing,worm shaft,housing,bearing,motor and so on. Motor drive the worm shaft, the outer ring of slewing bearing will rotate, the outer ring output the torque through flange while the inner ring of slewing bearing is fixed in housing.
| Brand | Titanhorse |
| Model | DA7 (7 inch dual axis slewing drive) |
| Rated Output Speed | 0.04rpm |
| Rated Ouput Torque | 722.7 N.m |
| Output Torque | 2600N.m |
| Tilting Moment Torque(Max.) | 13500 N.m |
| Holding Torque | 10400 N.m |
| Static Axial Load | 133 kN |
| Static Radial Load | 53 kN |
| Dynamic Axial Load | 32 kN |
| Dynamic Radial Load | 28 kN |
| Ratio Of Worm Gear | 73:1 |
| Tracking Precision | <0.2° |
| Application | solar tracker, antenna, automatic arm, construction machinery, Rader, Satellite, conveying equipments, transportation machinery etc. |
| Motor | DC(12v,24v,48v) AC(110V,220V,230V,380V,420V) Hydraulic Motor, Stepper Motor etc. |
| Life-time | 25-30 years |
| Materials | 42Crmo/ 50Mn |
| Seal | Grease Seal |
| Colour | according to your requirements |
