Specifications
boiler, circulator pump for boiler1. High thermal efficiency: > 98%.
2. Can work continuously 10000 hours
3. Siemens PLC co
boiler, boiler riello
- Brief introduction of the oil/gas fired steam boiler :
l Advanced three pass wet back design:adopts the most sophisticated three returns all wet back structure,thread smoke tube structure, weld joint with high quality.
l Advanced manufacturing equipment endows Safe and reliable property: adopts corrugated furnace lamps, multi-chain protection. Water level, steam pressure, gas pressure protection. And before leaving factory, all the boiler have been rigorous inspection and testing, including pressure tests and X-ray detection.
l Large boiler proper heating area:adopts unique design of a large combustion chamber which increases the radiation heating furnace area, reducing the size of the boiler, reducing the NOX emissions.
l High efficiency 98%:with threaded pipe and high effective insulation materials and econoizer, increasing the heat transfer and improve boiler thermal efficiency.
l PLC intelligent controller:boiler control system suitable for high temperature, high humidity environment of long-term operation.
l High standard: strictly in accordance with Chinese national norms and standards of production, all boiler pressure parts are of high quality steel.
l High quality accessories: all accessories such as burners, pumps, water level controller, valves and other supporting instruments of international or domestic famous brands.
l Simple maintenance: the manhole and hand hole is easy for user to maintain.
l Meet customer’s customized requirement:different designs are available according to customers' specific requirement.
- Application scope
l Industrial users: the pharmaceutical, paper making, tobacco, printing and dyeing, garment and other industries.
l Civil: catering, laundry room, (hospital) disinfection, sauna, etc.
l Heated by heat exchanger heating system soda <air conditioning, radiators, floor heating, etc.) hot water.
Vertical Steam Boiler Technical Parameter
Type |
Vertical Steam Boiler |
||||
Model |
LHS0.1- |
LHS0.2- |
LHS0.35- |
LHS0.5- |
|
Rated |
t/h |
0.1 |
0.2 |
0.35 |
0.5 |
Rated |
Mpa |
0.4/0.7 |
|||
Rated Steam Temperature |
°C |
152/171 |
|||
Thermal Efficiency |
% |
92% |
|||
Diesel |
Kg/h |
6.8 |
13.6 |
21 |
33.2 |
Natural Gas Consumption |
Nm3/h |
7.7 |
1615.21 |
26 |
37.5 |
Coal Gas Consumption |
Nm3/h |
18.3 |
36.4 |
64.3 |
92.1 |
Power |
V/Hz |
220/50 |
|||
Steam Outlet |
mm |
DN25 |
DN32 |
DN40 |
DN50 |
Water Inlet |
mm |
DN20 |
DN20 |
DN25 |
DN25 |
Drain |
mm |
DN25 |
DN25 |
DN40 |
DN40 |
Chimney |
mm |
φ 133 |
φ 159 |
φ 200 |
φ 200 |
Length |
mm |
1180 |
1176 |
1420 |
1420 |
Width |
mm |
1100 |
1100 |
1300 |
1300 |
Height |
mm |
1755 |
2142 |
2305 |
2670 |
Weight |
t |
0.76/0.78 |
0.92/0.96 |
1.40/1.54 |
1.68/2.30 |
