Electric Ceramic Tube Steam Boiler for Laundry

Name: Electric Ceramic Tube Steam Boiler for Laundry
Brand: Bidragon
SKU: 109867809
Availability: InStock

US$ 1,000 - 8,000 MOQ: 1 Short Ton

Key Specifications

Condition:

New

Type:

Natural Circulation

Usage:

Other, Hospital, school , restaurant

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Natural Circulation

Usage Other, Hospital, school , restaurant

Structure Other, Electric boiler

Pressure Low Pressure

Style Vertical

Fuel Other, electric

Place of Origin Shandong, China

Brand Name Bidragon

Model Number LDR0.05-0.7

Output Steam

Dimension(L*W*H) 600X1000X1500

Weight 90Kg

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Electric Ceramic Tube Steam Boiler
1.Stainless steel heating pipe
2.High efficient: 98%
3.Easy to install

Product Name

Siemen PLC 304 stainless steel Electric Heating Steam Boiler

Product Feature and Advantage

High thermal efficiency:> 98%.
Long lifespan seamless stainless steel heating pipe: our product passed the test of 10000 hours continuously working. Normal standard is 3000 hours.
High quality electric component: Schneider electric control components ensure the stability and good performance.
High intelligent PLC control: Siemens PLC control system with more intelligent function
High electrical conductivity: Pure cope electric wire and connector.
High quality boiler material: 12mm thickness boiler steel container.
Beautiful appearance for wide application: Stainless steel wire drawing cover, beautiful appearance, can be used in hospital, school, and restaurant .etc.

Technical Parameter

Small type electric heating steam generator: Vertical

Model	Steam Output Kg/h	Rated Power KW	Rated Operating Current A	Electric Cable Parameter	Outline Dimension mm	Weight Kg	Steam outlet Valve Diameter DN	Blown Down Valve Diameter DN	Water Inlet Valve Diameter DN
LDR0.05-0.7	50	36	55	3*25+2(Copper Cable)	600X1000X1500	90	25	25	15
LDR0.06-0.7	58	42	64	3*25+2(Copper Cable)	600X1000X1500	230	25	25	15
LDR0.07-0.7	68	48	73	3*25+2(Copper Cable)	600X1000X1500	230	25	25	15
LDR0.08-0.7	75	54	82	3*35+2(Copper Cable)	600X1000X1500	230	25	25	15
LDR0.09-0.7	85	63	95	3*35+2(Copper Cable)	600X1100X1600	240	25	32	15
LDR0.10-0.7	100	72	109	3*35+2(Copper Cable)	600X1100X1600	240	25	32	15
LDR0.11-0.7	112	81	123	3*50+2(Copper Cable)	600X1100X1600	240	25	32	15
LDR0.12-0.7	125	90	136	3*50+2(Copper Cable)	600X1100X1600	240	2$	32	15
LDR0.13-0.7	135	96	145	3*70+2(Copper Cable)	700X1200X1700	360	25	40	25
LDR0.15-0.7	150	108	164	3*70+2(Copper Cable)	700X1200X1700	360	25	40	25
LDR0.17-0.7	168	120	182	3*70+2(Copper Cable)	700X1200X1700	380	25	40	25
LDR0.20-0.7	200	144	218	3*95+2(Copper Cable)	700X1200X1700	380	25	40	25
