Specifications
coal slurry steam boiler1.Low temperature combustion
2.High combustion efficiency: 98%
3.High thermal efficiency:>89
Product name
Coal water slurry for Pakistan power plant
Application Scope:
Coal-water slurry (CWS) can be used in place of oil and gas in any size of heating and power station. CWS is suitable for existing gas, oil, and coal boilers.
Feature and advantage of coal-water slurry fired steam boiler
- Stable operation and low emission:Coal-water fluidization system realizes the low temperature combustion; avoid coking, unstable operation, poor security problem of Coal-water atomizer system.
- High efficiency:cyclic burn cluster of coal-water particle, achieve a high efficient performance reach 89%.
- No need for slag remover: fluidization combustion mode blow ash through the flue duct to the dust filter
- Long life span water coal slurry pelletizer machine: High quality atomization coal water slurry burner can use 1500h-2000h, but fluidization coal water slurry boiler do not need vulnerable and short lifespan burner, which means long life span.
- Low cost for desulfuration: Use limestone and silica sand as medium material cooperate with low temperature combustion technology realize the direct desulfuration during Coal-water combustion, which is simple structure and low cost.
- Low consumption for medium material:recycle of limestone increase the use ratio which reduce the supply of limestone and medium material. This system also increases the efficiency.
- Wide Load Adjustable Range: the boiler can adjust for different type Coal-water fuel and load range can be set 30% to 100%,
- Low cost and requirement for Coal-water:Wide adaptable for Coal-water fuel reduces the requirement for Coal-water manufacture, which reduce the Coal-water cost.
- Simple and stable accessory: SHFS series (CWS fluidization system) do not need expensive burner, fault liability CWS atomization gun, complex high pressure air and CWS system, which make the whole system simple and reliable.
- PLC control system
Technical parameter of SZS series coal-water slurry hot water boiler
Item |
SHFS4-1.25-J |
SHFS6-1.25-J |
SHFS10-1.25-J |
SHFS20-1.6-J |
SHFS35-3.82-J |
|
Rated Evaporation |
t/h |
4 |
6 |
10 |
20 |
35 |
Rated Working Pressure |
Mpa |
1.25 |
1.25 |
1.25 |
1.25 |
1.25 |
Steam Temperature |
°C |
Saturated |
Saturated |
Saturated |
Saturated |
450 |
Combustion Mode |
Chamber Combustion |
Chamber Combustion |
Chamber Combustion |
Chamber Combustion |
Chamber Combustion |
|
Applicable Fuel |
Coal-water |
Coal-water |
Coal-water |
Coal-water |
Coal-water |
|
Fuel consumption |
kg/h |
710 |
915 |
1615 |
2920 |
5713 |
Boiler Heating Area |
m2 |
145 |
208 |
246 |
469 |
/ |
Economizer Heating Are |
m2 |
60.3 |
72.4 |
206 |
351 |
/ |
Exhaust Gas Temperature |
°C |
166 |
163 |
157 |
157 |
/ |
Thermal Efficiency |
% |
85.8 |
85.9 |
90.8 |
88 |
/ |
Transportation Weight |
t |
31.5 |
35.5 |
Packaged |
Packaged |
/ |
Transportation Size |
mm |
6300*3100*3540 |
7100*3400*3540 |
Packaged |
Packaged |
Packaged |
Flowchart for System Equipment Allocation of CWM Fluidization
Picture of coal-water slurry boiler proper and accessory
