532nm 1064nm Dual Wavelength Waveplate
US$ 25 - 60
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jilin, China
Brand Name:
CCRQ
Model Number:
Waveplate
Payment & Shipping
Payment Methods:
Port of Shipment:
changchun Shenzhen Beijing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Achromatic WaveplatesUS$ 25 - 60MOQ: 10 Pieces -
True Zero Order Waveplate-Single PlateUS$ 25 - 50MOQ: 10 Pieces
-
True Zero Order Waveplate-CementedUS$ 25 - 60MOQ: 10 Pieces
-
Half Waveplates,Quarter Waveplates, Multiple-Order Quartz WavePlatesUS$ 25 - 45MOQ: 10 Pieces
-
1/2 Waveplates, Mounted Zero Order WavePlates 588nmUS$ 25 - 45MOQ: 10 Pieces
Place of Origin
Jilin, China
Brand Name
CCRQ
Model Number
Waveplate
Material
Other, Glass, Crystalline Quartz
Usage
Optical
Structure
Other, round
Shape
Plano
532nm 1064nm Dual wavelength waveplate
Introduction forDual wavelength waveplate
Dual Wavelength Waveplate is a multiple waveplate that provide a specitfic retardance at two different wavelengths, it's particularly useful when used in conjunction with other polarization sensitive components to separate coaxial laser beams of different wavelength.
Mainly Specifications | |
Material |
Quartz |
Typical Diameter |
10.0,12.7 15.0 20.0 30.0 |
Wavefront Distortion |
<lambda/8 at 632.8nm |
Retardation Tolerance |
<λ/300 (General), <λ/500 (High Precision) |
Wavelength Range |
240-2100nm |
Parallelism |
<3arc second.(General) , <1 arc second .(High Precision) |
Surface Quality |
20/10 S/D |
Coating |
R<0.2% on both surfaces at center wavelength |
