Yto Cpcd 25 China Forklift Manufacture Forklift Truck Forklift Diesel

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Evangel (Shanghai) Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI/QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPCD25

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 2500kg

Max. Lifting Height 6000mm

Min. Lifting Height 3300mm

Fork Length 1070mm

Fork Width 125mm

Overall Dimensions 2910mm*1480mm*2515mm

Certification ISO/CE

After-sales Service Provided Engineers available to service machinery overseas

yto cpcd 25 china forklift manufacture forklift truck forklift diesel

Product Description

Features of yto cpcd 25 china forklift manufacture forklift truck forklift diesel

1.5ton forklift China YTO DC Motor forklift truck CPD15
Power type Battary
Rated capacity 1.5ton
Motor 5-7.5kw

2.5ton forklift China YTO Diesel forklift truck CPCD25
Power type Diesel
Rated capacity 2.5ton
Engine xinchang 40kw

Parameters of yto cpcd 25 china forklift manufacture forklift truck forklift diesel

Model				CPCD25
Power type				Diesel
Rated capacity			kg	2500
Load center			mm	500
Lift height			mm	3300
Mast tilt angle (forward/backward)			Deg	5/15
Front overhang			mm	550
Wheel-base			mm	1850
Tread(front/rear)			mm	1250/1205
Travel brake				Hydraulic-Foot pedal
Parking brake				Mechanical-Hand level
Lift speed(with/without load)			mm/s	400/520
Lower speed (with/without load)			mm/s	(with load)300
Travel speed (with/without load)			km/h	18/23
Max. gradeability (with load)			%	17
Engine	Model			A495BPG
	Manufacturer			Xinchang
	Rated power		kw	42/2650
	Max.roration			174/1800
	Dispilacement			2.98
Battery	Voltage		V	12
	Capacity		Ah	100
Gearbox	Transmission type			Hydraulic
	Gears,speed (front/rear)			I/I
Tire	type			Spare tyres
	Model	Pront		11.5/80-15.3-14PR
		Rear		27×10-12-12PR
Self.weight			kg	4750
Free lift height			mm	120
Fork	Thickness×Width×Length		mm	40×125×1070
Overall dimensions	Overall length(without forks)		mm	2910
	Overall width		mm	1480
	Overall height	Extended height(mast)	mm	4270
		Lower height(mast)	mm	2310
		Overhead guard	mm	2515
Min. turning radius			mm	2940
Min. under ground clearance	Under mast		mm	220
	Center of wheel-base		mm	310
Optional engines:
Model		4TNE98
Manafacturer
Rated power KW		42.1/2300
Max.roration Nm/Rpm		186/1700
