Product: 180 Kw Six Cylinder Diesel Generating Set
Genset Technical Data | |
Prime power |
180kW / 225kVA |
Standby power |
198kW / 248kVA |
Rated speed |
1500 RPM |
Output frequency |
50 Hz |
Phase |
3 |
Engine model |
BF6M1015-LA GA |
Alternator model |
MP-180-4 |
Diesel Engine Technical Data | |
Engine Model |
BF6M1015-LA GA |
Configuration |
4 cycle , 6 cylinders in line |
Aspiration |
Turbocharged intercooled |
Bore×Stroke |
105x120 mm |
Rated speed |
1500rpm |
Displacement |
11.906L |
Prime Power |
120KW |
Speed Governor |
Mechanical/Electronic |
Cooling System |
Closed Water-cooled |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
205g/kw.h |
Starter Motor |
DC 24V |
Marathon Alternator Technical Data | |
Alternator model |
MP-180-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
200 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400V |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
Dimension and Weight(for reference only)
Overall size (L*W*H): 2850*1110*210mm
Weight: 2008kg
Control System HGM6110
All gensets have a control cubicle (the smart gen HGM6110 as standard) mounted on an isolated support, which has the following features.
The control module display
Generator voltage
Generator voltage
Output frequency
Engine speed
Battery voltage
Engine run-time (Hours)
The control module display for failure information
Overspeed / underspeed
Emergency stop
Low oil pressure
High water temperature
Failure to start
Battery charger failure
Automatic shutdown
Low engine oil pressure
High engine water temperature
Overspeed/underspeed
Failure to start after three attempts
Geneset options and Accessories
Generator set Alternator
Open genset PMG excitation
Trailer genset Space heater
Single phase genset Low environment temperature
ABB MCCB circuit breaker Water heater
Fuel system Battery heater
12 hours base tank (single wall) Oil heater
24 hours base tank (single wall)
Dual wall base fuel tank
Outside fuel tank
Control System
AMF function
ATS control cabinet
Multiple generator automatic synchrorising
