Specifications
AB-DN25C Program Controlled Torsion and Twist MachineThe dies come with the machine
6 sets for square steel: 25×2520×2018×1816×1614×1412×12
3 sets for flat iron: 30×820×616×5
Technological Depiction
|
|
AB-DN25C Program Controlled Torsion and Twist Machine |
|
Max Working Ability |
Length |
≤200800mm |
Specification |
≤25mm×25mm |
|
Motor Performance |
Power4KW Voltage380V |
|
Main Features |
1Manual setting and automatic repetition, guaranteeing the product processing homogeneity and reducing labor time and intensity. 2Spindle Speed uniform, bending coarse and ensure that the smaller profile, the machine can play the most effective role in its function 3It is easy to change the dies, only need several seconds. 4The max working ability is 25*25 square steel. And it can twist 4pcs φ12mm round steel or 12*12mm square steel together. 5It can twist 200-800mm pretzel. If the length exceeds 800mm, we can twist the part by segmentation method. With high production efficiency, it can twist 600pcs of 12*12mm square steel per hour. |
|
Packing Dimension |
1400mm*620mm*1100mm |
|
N.W. (kg) |
550 |
|
G.W. (kg) |
600 |
|
