Home > Instruments & Meters > Test Instrument > Test Machine > Rohde & Schwarz SMU200A Vector Signal Generator

Rohde & Schwarz SMU200A Vector Signal Generator

Name: Rohde & Schwarz SMU200A Vector Signal Generator
Brand: Rohde & Schwarz
SKU: 109773795
Availability: InStock

Rohde & Schwarz SMU200A Vector Signal Generator thumbnail-1

Rohde & Schwarz SMU200A Vector Signal Generator thumbnail-2

Rohde & Schwarz SMU200A Vector Signal Generator thumbnail-3

Rohde & Schwarz SMU200A Vector Signal Generator thumbnail-4

Rohde & Schwarz SMU200A Vector Signal Generator photo-1

Rohde & Schwarz SMU200A Vector Signal Generator photo-2

Rohde & Schwarz SMU200A Vector Signal Generator photo-3

Rohde & Schwarz SMU200A Vector Signal Generator photo-4

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Germany

Brand Name:

Rohde & Schwarz

Model Number:

SMU200A

Contact Supplier Request Quote Chat Now

Suzhou Youpin Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Germany

Brand Name Rohde & Schwarz

Model Number SMU200A

Power Other

Usage Other

Rohde & Schwarz SMU200A Vector Signal Generator

Product Description

Frequency options from 100 kHz to 2.2/3/4/6 GHz for the first RF path

Optional second RF path up to 2.2 GHz or 3 GHz

Up to two complete baseband paths

I/Q modulator with 200 MHz RF bandwidth

Very low SSB phase noise of typ. -135 dBc (f = 1 GHz, 20 kHz carrier offset, 1 Hz measurement bandwidth)

Wideband noise of typ. -153 dBc (CW, f = 1 GHz, >5 MHz carrier offset, 1 Hz measurement bandwidth)

Excellent ACLR of typically +70 dB for 3GPP FDD

Very high level repeatability of 0.05 dB

Baseband generator with universal coder for realtime signal generation

Arbitrary waveform generator with up to 64 MSamples

Intuitive user interface with graphical display of signal flow (block diagram)

Context-sensitive help system

ort frequency setting times (<3 ms); only 450 µs in List mode

Electronic attenuator up to 6 GHz over the full level range

Can be remote-controlled via GPIB and LAN

Digital Standard Eutra/LTE available

USB connectors for keyboard, mouse and memory stick

Many features for GPS option

Pulse Sequencer software generates complex pulses and bursts

Packaging & Shipping

Packing:

Carton packing
Pack the instrument with PE bubble bag
Foam-in-place to protect the instrument
Fasten the carton with Belt
Pack the carton with PE film to waterproof

Shipping:

All values are in USD and do not include the customs duties & taxes and other surcharges.

The instrument will ship out within 5 days upon payment received.

We usually choose FedEx/DHL International Economy. Other shipment way is also acceptable.

Our Services

30days warranty, No ROR
During the warranty date, the buyer can return the item if have quality problem.
If you want to return the instruments, the return item has to be the original packing. Without my permission, the instrument cannot be dismantled.
You are responsible for returning the item and paying for return shipping. The payment for the freight cost will not return. Only payment for the instrument will be refund.
The refund will complete within 7 working days after we receive the return items
