Help CenterGF2000P Andriod Handheld Pda With Thermal Printer
Related Products
GF2000P Handheld terminal with inbuilt printer
Free SDK is provided for customers' secondary development; Also we can customize the application software if required.
As specialized in this field for many years, we have accumulated a lot of experience in the following field
1. Travel & Ticket billing for Air Ticket, Railway, Subway, Taxi, Bus, Movie.
2. Electricity, Gas, meter reading and billing
3. Hotel/Supermarket/Retail/Restaurant/Convenience store management.
4. Lottery.
5. Surveying.
8) Other applications.
Main features:
- Android 4.0 or Wince 6.0operating system, easy to develop applications for them.
- 1G Hz ARM11 CPU makes sure the fast operating speed of the device.
- Seiko Printer 8/mm(203dpi)gives you a good resolution of the printing.
- GPRS/WCDMA/CDMA can be customized as your requirement
- RF/HF/UHF can be customized to match your system
- 1D/2D Barcode Supported
Characteristics |
|
|
|
|
|
CPU |
ARM11 1G Hz |
|
Memory |
2G |
|
Operating system |
Android 4.0 |
|
Communication |
USB2.0, 38K Infrared (Can transfer as far as 12 m.) |
|
External dimension |
200(l)*60(w)*50(h) mm |
|
Weight |
includes standardbattery320 g |
|
Display screen |
3.5-inch touch screen, 640 *480 dots |
|
Keyboard |
25Silicone Keyboard |
|
Battery |
Rechargeable battery2000mA/7.2 |
|
Expansion Slots |
MICRO SD card |
|
SIM card slot |
2 slots |
|
Audio |
High-volume speakers |
|
Camera |
300pixels, LE D flashlight |
|
Operating environment |
|
|
Working temperature -20℃to 50℃ |
|
|
Storage temperature |
-25℃ to 70℃ |
|
Humidity: |
5%RH - 95%RH(o condensation) |
|
Drop Specifications |
6 surfaces can withstand drops from 1.5 meters to concrete impact |
|
Scroll to specifications |
1,000 times 0.5 meters, six rolling contact surface |
|
Sealed environment |
IP64 |
|
|
|
|
E-Tag RF13.56mhz |
Supported Standards:EPC Gen 1 (0kind,1kind)and Gen 2 |
|
|
(Optional) |
Low working frequency:125kHz |
|
Tabdomining :EM 125KHz |
|
|
Working frequency of high frequency:13.56MHz |
|
|
protocol standard:ISO14443A/B,IS015693, |
|
|
Nominal read range:5.0cm to 10cm |
|
|
Rated write scope:5.0cm to 10cm |
|
|
Range:From the front of the device from the 70 ° angle (according to the band) |
|
|
Barcode Reader |
Optical Resolution: 0.005 inches minimum bar width |
|
|
(Optional)
|
Rotation angle: vertical deviation angle + / -30 |
|
Tilt angle: the angle from normal + / -65 ° |
|
|
Offset visual tolerance: deviation from the normal angle of + / -60 ° |
|
|
Ambient light: Sunlight: 8,000 ft.candles (86,112 Lux) |
|
|
Artificial light:450ft.candles(4,844Lux) |
|
|
Scanning Frequency: 50 scans per second (+ / -6) times (two-way) |
|
|
Scan Angle: 46.5 ° (standard) |
|
|
Laser power: 1.0 mA (standard) |
|
|
Reading accuracy:Laser greater than 6 mil |
|
|
Laser Safety: IEC 2 / FDA Ⅱ grade, standards compliance IEC60825-1/EN60825-1 |
|
|
GPS |
Accuracy of 3 m |
|
|
Wireless Communications (Optional) |
GSM/GPRS/EDGE: GSM850/EGSM900/DCS1800/PCS1900 WCDMA/HSDPA:2100M(band I),1900M(band II),850M(band V)CDMA2000 |
|
Wireless Module (Optional) Customized |
IRDA RF HF UHF |
|
|
|
|
Seiko Printer |
Paper Diameter:45mm |
|
Printing Method:Thermal line |
|
|
Resolution:8/mm(203dpi) |
|
|
Dots per line: 384dots,32 English characters/ line |
|
|
Print contents:Chinese, Numbers, English, all kinds of symbols |
|
|
Printing speed:50mm/s(adjustable) |
|
|
The way loading paper:Clamshell type paper |
|
|
Paper out test:When the printer runs out of paper function sounds |
|
|
Black Labeltest:yes |
|
|
|
|
|
