FU-25 Open Type / Split Core Current Transformer
USD $8 - $15
/ Unit
2 Units(Min.Order)
- 10000 Unit / Units per Month
- Beijing
- Credit Card PayPal
You May Like
-
Low voltage miniature zero phase current transformer
-
Waterproof 400 5a current transformer
-
GFUVE energy meter test equipment GF102 single phase watt-hour meter tester
-
testing equipment portable Three -Phase kwh Meter Testing set
-
handheld online 3 phase power quality analyzer
-
multi-functional network 0.5 class power meter
Product Details
| Place of Origin | Beijing, China | Brand Name | GFUVE | |
| Model Number | FU-25 |
Product Description
FU-25 Opening and closing installation type of current transformer
Product Description
Characteristic and application: Avaliable for cable that under 300A online measurement
Diameter of clamping wire: φ25MM
Overall dimensions:: 57MMx76MMx20MM
Load capacity: ≤4Ω
Installation: suspension, use the screws to tighten the opening
Output mode: lead output
Technical parameter
Primary current | Secondary current | Accuracy |
20A | 10mA | 0.2,0.5 |
30A | 30mA | 0.2,0.5 |
30A | 15mA | 0.2,0.5 |
30A | 10mA | 0.2,0.5 |
40A | 40mA | 0.2,0.5 |
40A | 20mA | 0.2,0.5 |
50A | 50mA | 0.2,0.5 |
50A | 25mA | 0.2,0.5 |
60A | 30mA | 0.2,0.5 |
60A | 20mA | 0.2,0.5 |
80A | 40mA | 0.2,0.5 |
100A | 50mA | 0.2,0.5 |
100A | 40mA | 0.2,0.5 |
300A | 150mA | 0.2,0.5 |
