Auomatic Pocket Spring Assembling Machinery

Name: Auomatic Pocket Spring Assembling Machinery
Brand: SOFTLIFE
SKU: 109753543
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Guangdong, China

Brand Name:

SOFTLIFE

Softlife Mattress Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

JIANGMEN WAIHAI PORT

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Guangdong, China

Brand Name SOFTLIFE

Model Number SL-12A

Voltage Customer's Requirement

Power(W) 3.5KW

Dimension(L*W*H) 3420*2370*2000mm

Weight 950kg

Certification CE\SGS

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

We sincerely invite friends from home and abroad to visit our company to negotiate

the price and procurement further our discussion on the later cooperation.

PRODUCT DESCRIPTION

SL12A is use for mattress, sofa pocket spring assembling. Gluing, turning and compressing could be finished automatically after putting the pocket spring strip into the box.
Using the slide way,to make the‘turning-compressing-reset ’action faster, more steady and high efficiency
Using the inverted triangle fixed plate, to make sure each pocket spring in the right position.
The traditional time delay spring positioning has replaced by the orientation of distance, to make it more accurate.
Achieve straight pattern and honeycomb type mattress;
Line glue spraying or point spraying mode could be chosen according to requirement.
With CE certification.

Technical specification

Pocket Height	100-220mm (custom-made)
Spring Diameter	55-65mm
Max. working width	2000mm
Gluing type	Interrupted,continuous ,or bit by bit
Working efficiency	3row/min(33pcs/row)
Air pressure	6KGS/cm3
Power	3.5kw
Weight	950kg
Dimensions	3420mm×2370mm×2000mm
