Main data of mobile scissor car lift
Hoist Mechanism, Dimensions and Weight (approx.)
Length(mm) |
Width(mm) |
Height(mm) |
Min.closing length(mm) |
Weight(kg) |
1722 |
525 |
430 |
1152 |
298 |
Hoist Cylinder and Pump Combination Specification (approx.)
|
Hoist Cylinder KRM160C |
Working Pressure(MPa) (Kgf/cm2) |
6.9 |
Gear Pump KP-75A/B
|
Standard Revolution (rpm) |
800 |
70 | |||||
Inner Diameter (mm) |
160 |
Discharge Volume(ml/rev.) |
72 |
||
Stroke (mm) |
755 |
Max. Testing Pressure(MPa) (Kgf/cm2) |
|
||
Min. mounting distance (mm) |
1075 |
20.6 |
|||
210 | |||||
Piston Rod diameter (mm) |
70 |
Weight(kg) |
22 |
||
|
Max. pressure (MPa) (Kgf/cm2) |
15.7 |
||||
160 |
Hoist Mounting and Maximum Lifting Capacity
Recommended Truck G.W.(kg) |
Body Length(mm) |
Rear Overhang Length(mm) |
Distance between Load Center and Hinge(mm) |
Distance between trunnion and Hinge(mm) |
Rated Lifting Capacity(kg) |
Designed Max. lifting Capacity(kg) (including load weight) |
11000-17000 |
4500 |
750 |
1500 |
2050 |
6000-8000 |
16000/52° |
Advantages of our products :
1. Using new rolling technology to ensure high precision for the inside hole of cylinder
2. The thickness of cylinder is up to 16mm,it can meet the strength requirement when the truck is overloaded
3. Using 3 seal-rings to seal piston rod ,it can be lifetime used
Quality Control :
1.Cylinder products have to pass strict quality control from purchasing materials, processing, assembling . (We passed the certification of ISO/ TS 16949:2009)
2.Automated cleaning equipment to ensure the cleanliness of fuel tank assembly.
3.Welding with CO2 arc and automatically girth welding, which can ensure the welding quality of the seal parts
4. Full Cylinder inspection, all products need to100% pass the comprehensive test before deliver out from factory.
Reference Datas for KRM Series Hydraulic Cylinder:
(We also produce custom made Hydraulic Cylinder according to your specific requirments)
| Model | Cylinder Inner Hole Diameter(mm) | Piston Rod Diameter(mm) | Stroke(mm) | Lifting Capacity(Ton) |
| KRM-92 | 160 | 45 | 405 | 4-5.5 |
| KRM-143A | 140 | 60 | 530 | 6-9 |
| KRM-160S | 160 | 70 | 604 | 8-11 |
| KRM-160C | 160 | 70 | 794 | 6-8 |
| KRM-183 | 180 | 80 | 832 | 21-29 |
| KRM-201 | 200 | 100 | 878 | 25-32 |
| KRM-220(48") | 220 | 100 | 1123 | 18-25 |
| KRM-220(68") | 220 | 100 | 1620 | 20-29 |
