Product Name
Edge Emitting 1pcs*SMD3535 Genesis 3W DC12V Constant Current IP65
LED Injection Module with heat sink-Eagle series
Product Advantage
1. Use high brightness Genesis 3535 as light source
2. Al substrate for LED components with well heat transfer
3. 45*15 degree wide Beam Angle
4. One-time Injection molding with own patent
5. Best sealed, waterproof IP65; 3-year Warranty
6. CE RoHS certified
Product Parameter
Parameters (Room temperature =25℃) | |||||||
Items |
Parameter |
Unit |
|||||
LED type |
SMD3535 Genesis |
|
|||||
LED Qtty |
1 |
PCS |
|||||
Concatenation |
20 |
PCS |
|||||
Dimension |
50*28*15 |
mm |
|||||
Power |
3.0±10% |
W |
|||||
Input V. |
DC12 |
V |
|||||
Input C. |
0.25 |
A |
|||||
Surface Temp. |
< 40 |
℃ |
|||||
Working Temp. |
-20 ~ +45 |
℃ |
|||||
Storage Temp. |
-30 ~ +60 |
℃ |
|||||
Protect Level |
IP65 |
- |
|||||
Optical and Electrical Parameters (Room temperature =25℃) | |||||||
Test Items |
Testing Condition |
Symbol |
Parameters |
Unit |
|||
|
|
|
Min |
Typical |
Max |
|
|
Color Temperature |
DC12V |
CCT |
5700 |
6000 |
6300 |
K |
|
Ra |
DC12V |
CRI |
|
80 |
|
-- |
|
Luminous Flux |
DC12V |
Φ |
- |
190 |
- |
lm |
|
Light Efficiency |
DC12V |
LPW |
- |
80 |
- |
lm/W |
|
Visual Angle |
DC12V |
Wd |
-- |
45*15 |
-- |
Deg |
|
Light Attenuation Graph
Light Distribution Curve:
Product Package
Product Application
Light boxes, Logo lighting, Advertising Signs, Back light source, Channel letters, etc.
Product Showcase
Factory View
Product Shipping
Our Exhibition
Why choose ZOYO LED?
1> Factory direct pricing
2> Factory customer support and service
3> In-house design and development
4> Experienced engineering
5> Quality assurance
6> Cost control due to vertical integration
7> In-house control of production
8> On time delivery control
Our Service
1. All your inquires will be replied within 12 hours
2. Well-trained and passional sales consultant who can speak fluent English
3. Offer OEM & ODM services. Can print your logo on product, can customize the retail box packing and other things.
4. Experienced R&D engineers with strong ability to do ODM projects.
More information, please feel free to contact us or send e-mail to info4(at).
FREE Samples are waiting for you. ^_^
