Home > Products > Injection LED Modules Series with lens > high power 3w led module edge emitting
high power 3w led module edge emitting
- 2 Piece / Pieces per Month
- Shenzhen/Hongkong
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Model Number: | ME501S | Chip Material: | InGaN | Emitting Color: | Cool White |
Luminous Flux(lm): | 195lm | Optical Attenuation(%): | 1% | Power: | 3W |
Power Dissipation: | 3W | Color Rendering Index(Ra): | 80 | Color Temperature: | 8000K |
Operating Temperature(℃): | -20, 45 | Storage Temperature(℃): | -30, 60 | Place of Origin: | Guangdong, China |
Brand Name: | ZOYO | Certification: | CE |
Product Description
Product Name
Edge Emitting 1pcs*SMD3535 Genesis 3W DC12V Constant Current IP65
LED Injection Module with heat sink-Eagle series
Product Advantage
1. Use high brightness Genesis 3535 as light source
2. Al substrate for LED components with well heat transfer
3. 45*15 degree wide Beam Angle
4. One-time Injection molding with own patent
5. Best sealed, waterproof IP65; 3-year Warranty
6. CE RoHS certified
Product Parameter
Parameters (Room temperature =25℃) | |||||||
Items | Parameter | Unit | |||||
LED type | SMD3535 Genesis |
| |||||
LED Qtty | 1 | PCS | |||||
Concatenation | 20 | PCS | |||||
Dimension | 50*28*15 | mm | |||||
Power | 3.0±10% | W | |||||
Input V. | DC12 | V | |||||
Input C. | 0.25 | A | |||||
Surface Temp. | < 40 | ℃ | |||||
Working Temp. | -20 ~ +45 | ℃ | |||||
Storage Temp. | -30 ~ +60 | ℃ | |||||
Protect Level | IP65 | - | |||||
Optical and Electrical Parameters (Room temperature =25℃) | |||||||
Test Items | Testing Condition | Symbol | Parameters | Unit | |||
|
|
| Min | Typical | Max |
| |
Color Temperature | DC12V | CCT | 5700 | 6000 | 6300 | K | |
Ra | DC12V | CRI |
| 80 |
| -- | |
Luminous Flux | DC12V | Φ | - | 190 | - | lm | |
Light Efficiency | DC12V | LPW | - | 80 | - | lm/W | |
Visual Angle | DC12V | Wd | -- | 45*15 | -- | Deg |
Light Attenuation Graph
Light Distribution Curve:
Product Package
Product Application
Light boxes, Logo lighting, Advertising Signs, Back light source, Channel letters, etc.
Product Showcase
Factory View
Product Shipping
Our Exhibition
Why choose ZOYO LED?
1> Factory direct pricing
2> Factory customer support and service
3> In-house design and development
4> Experienced engineering
5> Quality assurance
6> Cost control due to vertical integration
7> In-house control of production
8> On time delivery control
Our Service
1. All your inquires will be replied within 12 hours
2. Well-trained and passional sales consultant who can speak fluent English
3. Offer OEM & ODM services. Can print your logo on product, can customize the retail box packing and other things.
4. Experienced R&D engineers with strong ability to do ODM projects.
More information, please feel free to contact us or send e-mail to info4(at).
FREE Samples are waiting for you. ^_^
Thanks and Best regards,
Jacey Wu
Sales Manager
Email: info4(at)
Mobile/WhatsApp: +86-15919423655
