high bright smd3535 genesis led module back lit module led IP65

Name: high bright smd3535 genesis led module back lit module led IP65
Brand: ZOYO
Price: USD $1.36 - 1.58 / Piece

FOB Price

USD $1.36 - $1.58 / Piece

20 Pieces(Min.Order)

Supply Ability 2 Piece / Pieces per Month
Port Shenzhen/Hongkong
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Model Number:	ME501F	Chip Material:	InGaN	Emitting Color:	Cool White
Luminous Flux(lm):	195lm	Optical Attenuation(%):	1%	Power:	3W
Power Dissipation:	3W	Color Rendering Index(Ra):	80	Color Temperature:	8000K
Operating Temperature(℃):	-20, 45	Storage Temperature(℃):	-30, 60	Place of Origin:	Guangdong, China
Brand Name:	ZOYO	Certification:	CE

Product Description

Product Name

Back Lighting 1pcs*SMD3535 Genesis 3W DC12V Constant Current IP65

LED Injection Module with heat sink-Loong series

Product Advantage

1. Use high brightness Genesis 3535 as light source

2. Al substrate for LED components with well heat transfer
3. 160 degree wide Beam Angle
4. One-time Injection molding with own patent
5. Best sealed, waterproof IP65; 3-year Warranty
6. CE RoHS certified

Product Parameter

Parameters (Room temperature =25℃)
Items	Parameter				Unit
LED type	SMD3535 Genesis
LED Qtty	1				PCS
Concatenation	20				PCS
Dimension	502815				mm
Power	3.0±10%				W
Input V.	DC12				V
Input C.	0.25				A
Surface Temp.	< 40				℃
Working Temp.	-20 ~ +45				℃
Storage Temp.	-30 ~ +60				℃
Protect Level	IP65				-
Optical and Electrical Parameters (Room temperature =25℃)
Test Items	Testing Condition	Symbol	Parameters				Unit
			Min	Typical		Max
Color Temperature	DC12V	CCT	5700	6000		6300	K
Ra	DC12V	CRI		80			--
Luminous Flux	DC12V	Φ	-	195		-	lm
Light Efficiency	DC12V	LPW	-	80		-	lm/W
Visual Angle	DC12V	Wd	--	45*15		--	Deg

Light Attenuation Graph

Light Distribution Curve:

Product Package

Product Application

Light boxes, Logo lighting, Advertising Signs, Back light source, Channel letters, etc.

Product Showcase

Factory View

Product Shipping

Our Exhibition

Why choose ZOYO LED?

1> Factory direct pricing

2> Factory customer support and service

3> In-house design and development

4> Experienced engineering

5> Quality assurance

6> Cost control due to vertical integration

7> In-house control of production

8> On time delivery control

Our Service

1. All your inquires will be replied within 12 hours

2. Well-trained and passional sales consultant who can speak fluent English

3. Offer OEM & ODM services. Can print your logo on product, can customize the retail box packing and other things.

4. Experienced R&D engineers with strong ability to do ODM projects.

More information, please feel free to contact us or send e-mail to info4(at).

FREE Samples are waiting for you. ^_^

Thanks and Best regards,

Jacey Wu

Sales Manager

Email: info4(at)

Mobile/WhatsApp: +86-15919423655

Contact Us

Shenzhen ZOYO Optoelectronics Co., Ltd.: Contact nameZOYO LED; Phone86-755-29510699; AddressE Bldg.,Xinhui Ind.Park.,NO.3 Tangtou Ind. Zone,Shiyan Street,Baoan Dist. Shenzhen,Guangdong
