IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty

IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty thumbnail-1
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty thumbnail-2
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty thumbnail-3
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty thumbnail-4
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty thumbnail-5
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty photo-1
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty photo-2
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty photo-3
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty photo-4
IP65 Smd2525 Led Module 2W With Lens Waterproof High Power Led Module 12V 5 Year Warranty photo-5
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
Loong series-ML521F
Chip Material:
InGaN
Emitting Color:
Other, warm white/cold white
Contact Supplier Request Quote Chat Now
Shenzhen ZOYO Optoelectronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port/HK Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number Loong series-ML521F
Chip Material InGaN
Emitting Color Other, warm white/cold white
Luminous Flux(lm) 170
Power Other, 2W
Color Rendering Index(Ra) 83
Color Temperature 3000k/6000k
Operating Temperature(℃) -20, +45
Storage Temperature(℃) -30, +60
Place of Origin Guangdong, China
Brand Name ZOYO
Certification CE

IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



Product Advantage



1. Epistar LED, 5 Year Warranty

2. Constant current driving mode

3. Wide Beam Angle 165 degree

4. PMMA optic lens

5. High lumen & high power

6. Patented unique design

7. OEM/ODM available

8. CE & RoHS certified





Product Sketch





IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warrantyIP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



Product Parameter

 Parameters                          (Room temperature =25℃)

Items

Parameter

Unit

LED Type

CREE 2525



LED Quantity

1

PCS

Concatenation

20

PCS

Dimension

52*30*7.6

mm

Power

2 ±10%

W

Modules’ Centre Dis.

194

mm

Input V.

DC12V

V

Input C.

0.167

A

Drive Mode

Constant Current



Surface Temp.

< 45

℃

Working Temp.

-20 ~ +45

℃

Storage Temp.

-30 ~ +60

℃

Protect Level

IP65

-

 Optical and Electrical Parameters               (Room temperature =25℃)

Test Item

 Test Condition

Symbol

Parameters

Unit

Min.

Typical

Max.

Color Temperature

DC12V

CCT

5800

6500

7300

K

CRI

DC12V

CRI

70

75

80

Ra

Luminous Flux

DC12V

Φ

145

150

155

lm

Light Efficiency

DC12V

LPW

73

75

78

lm/W

Visual Angle

DC12V

Wd

155

160

165

Deg





IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty









IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty





Light Attenuation Graph

IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



Light Distribution Curve:



 IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



Instructions



1. Modules Positioning   (Vertical and Horizontal)



Item     Code

Light box thickness

DH(mm)

Module horizontal distance

DX(mm)

Module vertical

distance

DY(mm)

Module Qty.

in 1m2

(pcs/m²)

Surface illumination

(lux)

MD451F

150

170

170

35

780

Remarks:

1.The box panel is 3mm height acrylic board, 60% transmittance.





















2.Installation



-- Clean the fixation board and stabilize it.



-- Position the module with double sided tape and stick on the back of board.



-- Use silicon glue to fix modules (if needed).



-- Screw mounting the modules on the fixation board.





IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty

IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty







IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty





Product Application



IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty





Packaging & Shipping

Product Package





Shipping

1.FedEx/DHL/UPS/Russian express/ARAMEX for samples, Door-to-Door;

2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

3.Customers specifying freight forwarders or negotiable shipping methods;

4.Delivery Time: 3-5 days for samples; 10-15 days for batch goods.



Payment terms:

1. Payment: T/T, Western Union, PayPal,irrevocable L/C at sight; 30% deposits; 70% balance before delivery

2.MOQ:20 pcs

3.Warranty: 5 years

4.Package informations:1000pcs per carton/The volume of the box is 530mmx330mmx200mm.

Our Services

Why choose us?

1.We are Alibaba Assessed Gold Supplier;

2.We are a factory professional manufacturing Injection molding LED modules,Best production

capability,best quality control,Best service.

3.We have our own R&D engineers team,best product innovation capabilities;

4.100% QC inspection Before Shippment;

5.CE/ROHS listed,factory direct sales,competitive price.

Company Information

 Company View

IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warrantyIP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty

  IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty



Our certifications:CE/ROHS



IP65 smd2525 led module 2W with lens waterproof high power led module 12V 5 year warranty
