AC COB led chip high power 30w 40w 50w

Name: AC COB led chip high power 30w 40w 50w
Brand: FEDY
Price: Negotiable

FOB Price

Negotiable / Piece

50 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port Shenzhen
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

FEDY

Model Number:

AC COB led chip high power 30w 40w 50w

Product Description

AC COB led chip high power 30w 40w 50w

Company Information

1. FEDY is a professional manufacturer of Power led, led diode since 2000

2. Class A quality with 3 years warrany for all items.

3. Orignal Epistar/Bridgelux chips with 100% Class A grade.

4. All leds 100% QA passed before shipped.

5. Fully automatic production machine and quality checking machines insure great quality of goods , and fast delivery .

Product Description

AC COB led chip high power 30w 40w 50w

Item No.	Power	Emitting Size	Dimension	AC voltage	Intensity	CRI	Dimable
With wires behind , No need soldering---- 5W-20W
FD-2424-5	5W	Dia 23	24*24mm	110/220V	450-500	>75	Dimable
FD-2424-7	7W	Dia 23	24*24mm	110/220V	630-700	>75	Dimable
FD-2424-10	10W	Dia 23	24*24mm	110/220V	810-900	>75	Dimable
Illumination Diameter 11mm series -----5W-7W
FD-2022-5	5W	Dia 11	20*22mm	110/220V	450-500	>75	Dimable
FD-2022-7	7W	Dia 11	20*22mm	110/220V	630-700	>75	Dimable
Illumination Diameter 16mm series-----9W-12W
FD-2426-10	10W	Dia 16.5	24*26mm	110/220V	810-900	>75	Dimable
FD-2426-12	12W	Dia 16.5	24*26mm	110/220V	1080-1200	>75	Dimable
Illumination Diameter 20mm series-----5W-20W
FD-2630-5	5W	Dia 20	26*30mm	110/220V	450-500	>75	Dimable
FD-2630-7	7W	Dia 20	26*30mm	110/220V	630-700	>75	Dimable
FD-2630-10	10W	Dia 20	26*30mm	110/220V	810-900	>75	Dimable
FD-2630-12	12W	Dia 20	26*30mm	110/220V	1080-1200	>75	Dimable
FD-2630-15	15W	Dia 20	26*30mm	110/220V	1350-1500	>75	Dimable
FD-2630-20	20W	Dia 20	26*30mm	110/220V	1800-2000	>75	Dimable
Illumination Diameter 22mm series-----15W-30W
FD-3032-15	15W	Dia 22	30*32mm	110/220V	1350-1500	>75	Dimable
FD-3032-20	20W	Dia 22	30*32mm	110/220V	1800-2000	>75	Dimable
FD-3032-25	25W	Dia 22	30*32mm	110/220V	2250-2500	>75	Dimable
FD-3032-30	30W	Dia 22	30*32mm	110/220V	2250-2500	>75	Dimable
Illumination Diameter 25mm series-----20W-50W
FD-3040-20	20W	Dia 25	30*40mm	110/220V	1800-2000	>75	Dimable
FD-3040-30	30W	Dia 25	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-40	40W	Dia 25	30*40mm	110/220V	3200-3600	>75	Dimable
FD-3040-50	50W	Dia 25	30*40mm	110/220V	4000-4500	>75	Dimable
Illumination Diameter 28mm series-----20W-50W
FD-3040-20	20W	Dia 28	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-30	30W	Dia 28	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-40	40W	Dia 28	30*40mm	110/220V	3200-3600	>75	Dimable
FD-3040-50	50W	Dia 28	30*40mm	110/220V	4000-4500	>75	Dimable
Illumination Diameter 25mm*4 series-----100W-200W
FD-3040-100	100W	Dia 25	85*110mm	110/220V	2700-3000	>75	Dimable
FD-3040-120	120W	Dia 25	85*110mm	110/220V	2700-3000	>75	Dimable
FD-3040-160	160W	Dia 25	85*110mm	110/220V	3200-3600	>75	Dimable
FD-3040-200	200W	Dia 25	85*110mm	110/220V	4000-4500	>75	Dimable

Packaging & Shipping

Dip LED: ESD bag, Reel& Tape

High power led : ESD box .ESD bag, Tube

Super flux led : ESD bag. Tube

SMD LED : Reel

Our Services

1. Highest quality

2. Bst price

3.Fast delivery

4. Class A service

Part No.	Power	CCT	Intensity	Voltage	Current	CRI
FD-COB-3W	3W	3000K	250-280lm (230-250lm)	9.0—10.2V	350mA	≥70 (80)
FD-COB-3W	3W	5500K	290-310lm	9.0—10.2V	350mA	≥70
FD-COB-4W	4W	3000K	340-380lm(300-340lm)	12.0—13.6V	350mA	≥70 (80)
FD-COB-4W	4W	5500K	380-420lm	12.0—13.6V	350mA	≥70
FD-COB-5W	5W	3000K	420-480lm(380-420lm)	15.0—17.0V	350mA	≥70 (80)
FD-COB-5W	5W	5500K	480-530lm	15.0—17.0V	350mA	≥70
FD-COB-6W	6W	3000K	510-570lm(450-510lm)	18.0—20.4V	350mA	≥70 (80)
FD-COB-6W	6W	5500K	570-630lm	18.0—20.4V	350mA	≥70
FD-COB-7W	7W	3000K	600-660lm(520-600lm)	21.0—23.8V	300mA	≥70 (80)
FD-COB-7W	7W	5500K	660-730lm	21.0—23.8V	300mA	≥70
FD-COB-8W	8W	3000K	680-760lm(600-680lm)	24.0—27.2V	300mA	≥70 (80)
FD-COB-8W	8W	5500K	760-840lm	24.0—27.2V	300mA	≥70
Part No.	Power	CCT	Intensity	Voltage	Current	CRI
FD-COB-30W	30W	3000K	2300-2700lm	30.0—34.0V	900mA	≥80
FD-COB-30W	30W	5500K	2900-3200lm	30.0—34.0V	900mA	≥70
FD-COB-25W	25W	3000K	2100-2350lm	30.0—34.0V	750mA	≥80
FD-COB-25W	25W	5500K	2400-2650lm	30.0—34.0V	750mA	≥70
FD-COB-20W	20W	3000K	1600-1800lm	30.0—34.0V	600mA	≥80
FD-COB-20W	20W	5500K	2000-2200lm	30.0—34.0V	600mA	≥70
