12V DC COB Led Liner Type 12w 24w

12V DC COB Led Liner Type 12w 24w thumbnail-1
12V DC COB Led Liner Type 12w 24w photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FEDY
Model Number:
12V DC COB led liner type 12w 24w
Contact Supplier Request Quote Chat Now
Shenzhen Fedy Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name FEDY
Model Number 12V DC COB led liner type 12w 24w

12V DC COB led liner type 12w 24w

Company Information



1.  FEDY is a professional manufacturer of Power led, led diode since 2000

2. Class A quality with 3 years warrany for all items.

3. Orignal Epistar/Bridgelux chips with 100% Class A grade.

4. All leds 100% QA passed before shipped.

5. Fully automatic production machine and quality checking machines insure great quality of goods , and fast delivery .

12V DC COB led liner type 12w 24w


Product Description
AC 110V 220v COB power led module 20w 30w 40w 50w
Item No. Power Emitting Size Dimension AC voltage Intensity CRI Dimable
With wires behind , No need soldering---- 5W-20W
FD-2424-5 5W Dia 23 24*24mm 110/220V 450-500 >75 Dimable
FD-2424-7 7W Dia 23 24*24mm 110/220V 630-700 >75 Dimable
FD-2424-10 10W Dia 23 24*24mm 110/220V 810-900 >75 Dimable
Illumination Diameter 11mm series -----5W-7W
FD-2022-5 5W Dia 11 20*22mm 110/220V 450-500 >75 Dimable
FD-2022-7 7W Dia 11 20*22mm 110/220V 630-700 >75 Dimable
Illumination Diameter 16mm series-----9W-12W
FD-2426-10 10W Dia 16.5 24*26mm 110/220V 810-900 >75 Dimable
FD-2426-12 12W Dia 16.5 24*26mm 110/220V 1080-1200 >75 Dimable
Illumination Diameter 20mm series-----5W-20W
FD-2630-5 5W Dia 20 26*30mm 110/220V 450-500 >75 Dimable
FD-2630-7 7W Dia 20 26*30mm 110/220V 630-700 >75 Dimable
FD-2630-10 10W Dia 20 26*30mm 110/220V 810-900 >75 Dimable
FD-2630-12 12W Dia 20 26*30mm 110/220V 1080-1200 >75 Dimable
FD-2630-15 15W Dia 20 26*30mm 110/220V 1350-1500 >75 Dimable
FD-2630-20 20W Dia 20 26*30mm 110/220V 1800-2000 >75 Dimable
Illumination Diameter 22mm series-----15W-30W
FD-3032-15 15W Dia 22 30*32mm 110/220V 1350-1500 >75 Dimable
FD-3032-20 20W Dia 22 30*32mm 110/220V 1800-2000 >75 Dimable
FD-3032-25 25W Dia 22 30*32mm 110/220V 2250-2500 >75 Dimable
FD-3032-30 30W Dia 22 30*32mm 110/220V 2250-2500 >75 Dimable
Illumination Diameter 25mm series-----20W-50W
FD-3040-20 20W Dia 25 30*40mm 110/220V 1800-2000 >75 Dimable
FD-3040-30 30W Dia 25 30*40mm 110/220V 2700-3000 >75 Dimable
FD-3040-40 40W Dia 25 30*40mm 110/220V 3200-3600 >75 Dimable
FD-3040-50 50W Dia 25 30*40mm 110/220V 4000-4500 >75 Dimable
Illumination Diameter 28mm series-----20W-50W
FD-3040-20 20W Dia 28 30*40mm 110/220V 2700-3000 >75 Dimable
FD-3040-30 30W Dia 28 30*40mm 110/220V 2700-3000 >75 Dimable
FD-3040-40 40W Dia 28 30*40mm 110/220V 3200-3600 >75 Dimable
FD-3040-50 50W Dia 28 30*40mm 110/220V 4000-4500 >75 Dimable
Illumination Diameter 25mm*4 series-----100W-200W
FD-3040-100 100W Dia 25 85*110mm 110/220V 2700-3000 >75 Dimable
FD-3040-120 120W Dia 25 85*110mm 110/220V 2700-3000 >75 Dimable
FD-3040-160 160W Dia 25 85*110mm 110/220V 3200-3600 >75 Dimable
FD-3040-200 200W Dia 25 85*110mm 110/220V 4000-4500 >75 Dimable





Packaging & Shipping





Dip LED:  ESD bag,  Reel& Tape
High power led : ESD box .ESD bag, Tube
Super flux led : ESD bag. Tube
SMD LED : Reel







Our Services



 1. Highest quality

 2. Bst price

 3.Fast delivery

 4. Class A service



 12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w

 12V DC COB led liner type 12w 24w

Part No. Power CCT Intensity Voltage Current CRI
FD-COB-3W 3W 3000K 250-280lm (230-250lm) 9.0—10.2V 350mA ≥70 (80)
5500K 290-310lm 9.0—10.2V 350mA ≥70
FD-COB-4W 4W 3000K 340-380lm(300-340lm) 12.0—13.6V 350mA ≥70 (80)
5500K 380-420lm 12.0—13.6V 350mA ≥70
FD-COB-5W 5W 3000K 420-480lm(380-420lm) 15.0—17.0V 350mA ≥70 (80)
5500K 480-530lm 15.0—17.0V 350mA ≥70
FD-COB-6W 6W 3000K 510-570lm(450-510lm) 18.0—20.4V 350mA ≥70 (80)
5500K 570-630lm 18.0—20.4V 350mA ≥70
FD-COB-7W 7W 3000K 600-660lm(520-600lm) 21.0—23.8V 300mA ≥70 (80)
5500K 660-730lm 21.0—23.8V 300mA ≥70
FD-COB-8W 8W 3000K 680-760lm(600-680lm) 24.0—27.2V 300mA ≥70 (80)
5500K 760-840lm 24.0—27.2V 300mA ≥70
Part No. Power CCT Intensity Voltage Current CRI
FD-COB-30W 30W 3000K 2300-2700lm 30.0—34.0V 900mA ≥80
5500K 2900-3200lm 30.0—34.0V 900mA ≥70
FD-COB-25W 25W 3000K 2100-2350lm 30.0—34.0V 750mA ≥80
5500K 2400-2650lm 30.0—34.0V 750mA ≥70
FD-COB-20W 20W 3000K 1600-1800lm 30.0—34.0V 600mA ≥80
5500K 2000-2200lm 30.0—34.0V 600mA ≥70

  12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w12V DC COB led liner type 12w 24w
