Sinter Curved Teeth Bevel Gear for Power Tool

US$ 0.5 - 0.8 MOQ: 1000 Pieces

Key Specifications

Tooth Profile:

Helical Gear

Direction:

Left Hand

Material:

Other, Powder metal

Hefei Bolin Advanced Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Tooth Profile Helical Gear

Direction Left Hand

Material Other, Powder metal

Processing Other, Sinter

Place of Origin Anhui, China

Standard or Nonstandard Nonstandard

Specifications

1. Professional manufacturer
2. Sinter curve-teeth bevel gear for power tool
3. High density to 7.2 g/cm2
4. Heat treatment

Product Name	Sinter Curve-teeth Bevel Gear for Power Tool
Raw Materials	Hot press metal powder from QMC, FS807WP
Feature	1. Density: No less than 7.2g/cm3 2. Hardness: HBC 35-42 after carbonnitriding heat treatment.
Application	Power tool, Electric tool.
Processing	Mixing powder——Forming——Sintering——Carbonnitriding heat treatment——Internal boring——Polishing——Packing
Manufacturability	1. Auto Press: 50T, 100T, 140T, 260T 2. Hydraulic Press: 100T, 315T, 500T, 630T 3. Six sinter furnaces, including one harden Sinter Furnace 4. Heat treatment: Carbonitriding quenching and high frequency induction quenching in-house. 5. Pedrail ultrasonic cleaner line and auto deburring 6. In-house tooling making: EDM, wire cutting machine 7. Strength in machining: Machine center, CNC milling, CNE lathe, Two end lapper, polisher etc.
Measuring devices	1. Carbon selfur determinator 2. Metallurgic microscope 3. Hydraulic universal material tester 4. Hardness testers 5. Pneumatic measuring instrument 6. Measuring projector 7. Gear testing instrument 8. Electrical profilometer 9. CMM
QMS	ISO9001:2008, ISO/TS16949:2009, ISO14000:2004, OHSAS18001:1999
Advantage	1. Well experienced OEM manufacturer 2. 15 years in the powder metallurgy industry 3. Professional technology service
