Enclosure constant current 3000mA 36W led driver module
PRODUCT ATTRIBUTE
Item No. |
AT30U12-37 | AT30U24-37 | AT36U12-37 |
Rated Load |
30W |
30W |
36W |
Output Voltage |
12V DC |
24V DC | 12V DC |
Output Current |
2500mA |
1250mA | 3000mA |
Input Voltage |
100-240VAC 50/60Hz |
||
Conversion Efficiency |
≥78% |
||
Power factor |
PF≥0.95 |
||
Dimension |
131*44*22MM |
||
Working temperature |
-30~+50°C |
||
Temperature Rise |
≤30°C |
||
Storage temperature |
-30~+100°C |
||
IP code |
IP20 |
||
Brand |
ALLTOP & Customized |
||
Warranty |
3 years |
||
Certificate |
CE, ROHS, TUV, SAA, EMC, LVD |
||
Application |
LED ceiling light,LED down light,led panel light, Indoor etc. |
||
Packing |
Standard export packing/ according requirement. |
||
Pieces per carton |
100pcs/ctn |
||
Deliver |
Samples :1-3 days.Orders more than 10000unit in 7-15days |
||
Payment terms |
By T.T, Western Union, L/C, etc |
||
Small size,High efficiency,High reliability,Long lifetime;
IP44 rating;
Working temperature -25~+50°C
Protection:Overload,Short-circuit pratection,Over-temperature;
Typical efficiency:85%
Low standby power,min to 0.5W;
Start delay design,which can reduce the starting current when multiple simulatance start;
CE,EMC,IP20 certifide,ROHS compliant;
Low output ripple moises.
