High Efficiency 12w 500ma Constant Current Led Supplies

Name: High Efficiency 12w 500ma Constant Current Led Supplies
Brand: ALLTOP
SKU: 109673429
Availability: InStock

US$ 2 - 3 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ALLTOP

Model Number:

AT12C500-46

Zhongshan Alltop Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

zhongshan shenzhen guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ALLTOP

Model Number AT12C500-46

Output Power Other, 12W

Output Type Multiple

Input Voltage Other, 100-240VAC, 100-240VAC

Output Voltage 9-21VDC

Output Frequency 50/60hz

Output Current 650-700mA

High efficiency 12w 500ma constant current led supplies

PRODUCT ATTRIBUTE

Item No.	AT15C700-46	AT12C500-46	AT12C600-46
Rated Load	15W	12W	12W
Output Voltage	8-18V DC	8-22V DC	11-22V DC
Output Current	650-700mA	450-600mA	550-600mA
Input Voltage	100-240VAC 50/60Hz
Conversion Efficiency	≥78%
Power factor	PF≥0.95
Dimension	883822MM
Working temperature	-30~+50°C
Temperature Rise	≤30°C
Storage temperature	-30~+100°C
IP code	IP20
Brand	ALLTOP & Customized
Warranty	3 years
Certificate	CE, ROHS, TUV, SAA, EMC, LVD
Application	LED ceiling light,LED down light,led panel light, Indoor etc.
Packing	Standard export packing/ according requirement.
Pieces per carton	100pcs/ctn
Deliver	Samples :1-3 days.Orders more than 10000unit in 7-15days
Payment terms	By T.T, Western Union, L/C, etc
