Position Switch LW26GS (ROHS,CE Certificate) With Indicating Light and Keylock

Name: Position Switch LW26GS (ROHS,CE Certificate) With Indicating Light and Keylock
Brand: cansen
SKU: 109667189

US$ 2 - 18 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

cansen

Model Number:

LW26GS

Wenzhou Changjiang Electrical Appliance Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name cansen

Model Number LW26GS

Max. Current 40

Max. Voltage 660

Mechanical Life 100000

Specifications

position switch,
current range:10A to 160A
certificate:Rohs&CE
IP class:IP65

position switch LW26GS (ROHS,CE certificate) with indicating light and keylock

No.	Tech Parameters	requirement
1.	rated voltage	below 440V & DC220
2.	rated current	10A,20A,25A,32A,63A,80A,100A,125A,160A
3.	frequency	AC50HZ
4.	No.of poles	2P,3P,4P
5.	No.of layers	make as required with circuit diagram
6.	panel size	3030mm,4848mm,6464mm,8888mm
7.	colour of handle	black,white,red,grey
8.	Working temperature	-25°C~+40°C REMARKS:the average temperature mustn’t be pass 35°C
9.	Working height	≤2,000m
10.	Relative humidity	≤50% with highest temperature +40°C,but allow higher humidity with low temperature less than 40°C (eg.:humidity 90%----teperature20°C)
11.	Instalation conditions	polution class III
12.	Mechanical life	0.1*10⁶times
13.	Electrical life	0.03*10⁶times
14.	Operative frequency	120times/hour
15.	transform angle	30°/45°/60°/90°/120°/135°/150°
