Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > Screw Pump Stator of Solids Control Mud System

Screw Pump Stator of Solids Control Mud System

Name: Screw Pump Stator of Solids Control Mud System
Brand: Brightway
SKU: 109662469
Availability: InStock

Screw Pump Stator of Solids Control Mud System thumbnail-1

Screw Pump Stator of Solids Control Mud System photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shaanxi, China

Brand Name:

Brightway

Model Number:

BWG40-1

Contact Supplier Request Quote Chat Now

Xi'an Brightway Energy Machinery Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shaanxi, China

Brand Name Brightway

Model Number BWG40-1

Usage Oil

Power Other, Electric, 4KW

Standard or Nonstandard Standard

Product Description

Brightway Screw Pump Advantages

Screw Pump widely used for: Environment protection,Shipbuilding industry, Brewing Industry,Petroleum Industry.

Brightway BWG Screw Pump Series Products adopt high-performance motor,Good-quality material. Long life, Strong mud-processing capability.
Screw Pump also called Centrifuge feed pump, which is speed adjustable and can be matched with decanter centrifuge. The main parts are screw shaft (rotor) and screw shaft bushing (stator). The fluids flow along with the shaft, inner flow speed is slow and capacity remains, pressure is steady, so it will not generate vortex and agitating. The rated pressure of pump outlet increases by the pump grade rising, and each grade rising brings the pressure increase 0.6 MPa.

Product Parameters

Brightway Screw Pump Parameters

Model	Capacity	Pressure	Max Speed	Power	Inlet	Outlet	Max solids
BWG40-1	12m³/h	0.6Mpa	960RPM	4Kw	80mm	65mm	3.8mm
BWG50-1	14m³/h	0.6Mpa	720RPM	5.5Kw	100mm	80mm	5.0mm
BWG60-1	22m³/h	0.6Mpa	720RPM	11Kw	120mm	100mm	6.0mm
BWG70-1	40m³/h	0.6Mpa	720RPM	11Kw	150mm	125mm	8.0mm
BWG85-1	56m³/h	0.6Mpa	630RPM	15Kw	150mm	150mm	10.0mm
BWG105-1	100m³/h	0.6Mpa	500RPM	30Kw	80mm	65mm	15.0mm
