Help Center280KG 600lbs LED Time Delay EM Lock
Related Products
-
JA280A Magnetic Locks, Electric Control LockNegotiableMOQ: 50 Pieces -
Magnetic LockNegotiableMOQ: 50 Pieces
-
180KG 350lbs Magnetic Lock With Signal Output for Sliding DoorNegotiableMOQ: 50 Pieces
-
Flat Tumbler Mechanism Cylinder With Higher Resistance to Resist Violence(YP-H)NegotiableMOQ: 90 Sets
-
Cylinder of 304 Stainless Steel With Flat Tumbler Mechanism(YP-30)NegotiableMOQ: 90 Sets
The company's products are fashionable and the beautiful, safe and reliable performance in line with national standards. Applied to access control, building intercom, office space, emergency exits, and other occasions.
Hardened aluminum alloy, satin surface blasting, durable and beautiful.
High-quality professional magnetic materials, high-quality silicon steel, pure enamelled copper wire, with professional process, achievements of all safety equipment and stable quality electronic lock.
Magnetic lock (or electromagnetic lock) design is used of electromagnetic theory, the same as the electromagnet. When the current through the silicon steel, magnetic locks will produce powerful suction, iron will be suck tightly; Magnetic locks brings in a huge magnetic force even under a very small current, thereby make effective control of the doors switch.
Single door electric magnetic lock is used forWooden door,Glass door,Metal door, Fireproof door, easy to install, Low noise,long serving lifewith strong suction power. higher quality and reliable performance.
| Size | 231.6Lx41.6Wx24.5H(mm) |
| Armature Plate Dimension | 180Lx38Wx11H(mm) |
| Holding Force | 280kg(600Lbs) |
| Input Voltage | 12 or 24VDC |
| Current | 12V/500mA or 24V/250mA |
| Suitable | Wooden door , Glass door ,Metal door , Fireproof door |
| Surface Temp | ≤+20°C |
| Operating Temp | -10~+55°C(14-131F) |
| Humidity | 0~90%(non-condensing) |
| Cover Finish | Anodized aluminum |
| Lock Finish | Zinc |
| Armature Plate Finish | Zinc |
| Weight | 2.1kg |
Advantage:
Our magnetic lock have the below advantage worthy for you choose:
1, The holding force of magnetic lock is the best In China(the holding force is higher 20% than other manufacturers).
2, The coil of our magnetic lock is pour copper not copper-clad aluminum
3, Shell is made of high-strength aluminum alloy.
4,The speciall desigh protect the PCB of magnetic lock moistureproof.
5,the PCB and the lock body connect by chip not traditonal wire.
6,Suction plate can resist the residual magnetic .
7,Buit-in reverse current protection device(MOV)
