Specifications
4:3 LCD High resolution 800X600, up to 1024X768 max350cd/m2, 400:1 Wide view angle
AV1+AV2+VGA input
24 month warranty
Best quality HD 8 inch TFT LCD AV1 + AV2 + VGA Monitor
( AV1 + AV2 + BNC / AV1 + AV2 + Touch screen is optional )
Model No.: MPC-808
8 inch Digital TFT Touch Monitor
Description: 8″ TFT LCD Monitor with VGA port
Case/Bezel Colour: Black
Display Type: 4:3 Ratio 8″Active Matrix TFT LCD
Active DisplayArea: 162(W) X 121.5(H) mm
Native Resolution :800 x 600 @ 60Hz _1024 x 768 @ 75Hz
Sychronization Range: 30-80 KHz horizontal, 55-75 Hz Vertical
Pixel Pitch: 0.0675(W) X 0.2025(H) mm
Pixel Response Time Rise + Fall (Typically): 12ms
Plug and Play: VESA DDC 1/2B
On Screen Display (OSD): Remote OSD
Colours: 16.7 million
Brightness: 350 cd/m2
Contrast Ratio Typically: 400:1
ViewingAngle Horizontal (left/right): 170degreen (85degreen/85degreen)
(From Centre, CR>=5) Vertical (up/down): 160degreen (70degreen/90degreen)
Backlight Lamp life Hrs to 1/2 brightness: 50,000
Input Video Format: Analog RGB ,NTSC/PAL/SCAME(AUTO)
Monitor Dimensions: 205 x 163 x 31(mm)
Shipping Carton Dimensions: 250 x 85 x 403(mm)
Provider Weight (approximately) Monitor/Shipping: 1.5kg
Power Supply: External: 85-265VAC, 50-60 Hz
Power Consumption: <10 W Typ
Temperature Range: Operating:0C-50C,
Storage:-20C-80C
Relative Humidity Non Condensing: Operating:10%-90%, Storage 5%-90%
Warranty: 2 years
AgencyApprovals: FCC, CE, RoHS
Accessories
VGA cable
Remote
Power Supply Adaptor
User Manual (English only)
Bracket
