Small Lift Tilt Work Welding Positioner Chuck For Sale

Specifications

It is is mainly used to place the workpiece in the best position for welding and assembling.







1. Universal Welding Positioner







1.1 Feature



1. Welding positioner is mainly composed of worktable revolving unit and tilting unit and electric control system .

2. It has powered tilting and revolves, making the work-piece at ideal position .

3. Worktable rotation is controlled by step-less frequency conversion to achieve a best welding speed .

4. Revolve unit is driven by motor. It has a precise speed-adjusting and reliable position.

5. Remote control box can realize the remote operation of work bench, also can connect with operating machines to realize linkage operation.

6. Set aside interface to realize linkage work with manipulator and hanging automatic welding machine achieve automatic welding center .

7. Used to pressure vessel, metallurgy, electrical power, chemical industry, mechanical and metal structure .



1.2 Technical parameters





2. Double Column Positioner





2.1 Feature



1. Mainly used for work piece which is big and with irregular shape.

2. With function of ±90°tilting. The tilting speed could be fixed speed or adjustable.

3. With function of lifting. Lifting stoke depends on customers’ requirement.

4. With function of 360°rotating. The tilting speed could be fixed speed or adjustable.

5. With function of tilting self-lock.

6. We will design according to customers' requirement.



2.2 Technical parameters

Double Column Positioner - BHBS Series
Model	BHBS50	BHBS100	BHBS200	BHBS300	BHBS500	BHBS1000
Load Cap.(kg)	5000	10000	20000	30000	50000	100000
Rotation Speed(rpm)	0.05-0.5	0.05-0.5	0.04-0.4	0.03-0.3	0.02-0.2	0.01-0.1
Tilting Speed(rpm)	0.2	0.1	0.1	0.1	0.1	0.1
Table Dia. (mm)	Φ2500	Φ2500	Φ3000	Φ3500	Φ4000	Φ4000
Maximum Eccentricity(mm)	200	200	200	200	200	200
Max Gravity Center Distance(mm)	600	600	1000	1500	2000	2500
Rotary Motor Power(Kw)	3	4	5.5	7.5	11	18.5
Tilting Motor Power(Kw)	2×2.2	2×3	2×5.5	2×7.5	2×11	2×15
Speed Mode	AC frequency converter stepless speed adjustment
Above are the standard parameter also we can design according to the customer requirement .
