luoyang 1000mm longitudinal seam welders/seam welder

Specifications

1. High quality automatic straight welding
2. Imported electrical components.
3. Effence, Durable and stable.
4. ISO9001

Automatic TIG/MIG Straight (Longitudinal) Seam Welding Machine



Feature



1. Longitudinal Seam Welding Machine mainly includes two parts: Automatic Machinery Part and Welding Source.



2. The Machinery Part is designed as Keyboard Type Copper Pressing Mechanism, to get the regular and stable clamping and cooling effect.



3. Automatic Machinery Part is adopted PLC controller. DC motor drive has stepless adjustable welding speed and interfaces with any power source.



4. Welding Source Part includes TIG (tungsten inert gas shielded arc welding), MIG (metal inert gas shielded arc welding) MAG (metal active gas arc welding), SAW (submerged arc welding), PAW(plasma arc welding),etc. Well-known brands of welding power are is optional.



5. Weld Seam back up design has a groove to form a weld on the bottom of a welded plate and provide consistent gas flow to the back of the weld, to assure the stable gas shield and ensure double-side forming in single side welding.



6. It is mainly used for the high quality and low distortion automatic straight welding, such as metallic cylinders and aligned plates made with stainless steel , iron , aluminum and brass, etc.



7. High welding efficiency and speed, well welding quality and good consistency.



 Technical parameter



Model	BLW-300
Input Voltage	220V/380V/440V/480V,50/60Hz
Max Welding Length	2100mm
Workpiece Dia.	300-1100mm
Workpiece Thickness	0.5-30mm
Welding Speed	75-1500mm/min
Above are the standard parameter also we can design according to the customer requirement.
