Metal H Beam Gantry Welding Equipment
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | BOTA | |
| Model Number | other | Voltage | 380V/50Hz,or according to your need | |
| Current | standard | Rated Capacity | standard | |
| Rated Duty Cycle | standard | Dimensions | standard | |
| Weight | standard | Usage | H beam welding,Vessel welding | |
| Certification | ISO9001-2008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
metal H beam gantry welding equipment
Gantry Type Welding machine
This machine is designed according to the vessel welding. It mainly consist of Gantry frame, slide structure, welding gun tracking device, Flux recovery system, electrical control system and Submerged welding machine. Gantry frame is main part of machine.
1. Feature
1. Gantry structure: gantry frame, walking structure, motorized slide structure, wire reel bracket, weld wire feeder accessory etc.
2. Welding boom and carriage: welding boom mechanical transmit structure and corresponding accessory (two sets)
3. Arc guiding structure: including welding gun manual adjust structure, arc guiding frame, welding gun and gas pulling machinery adjust structure (2 sets)
4. Flux recover system: 100kg flux recover machine and corresponding accessory
5. Welding system: MZ-1000 Submerged arc welding machines 2 sets
6. Seam tracking system.
7. Electric control system: electric control board, AC inverter, control box,, light etc.
2.Technical parameter
H-beam Welding Machine | |
Model | BGHW-2 |
piece flange width | 200-800mm |
piece web height | 200-1500mm |
3.Workpiece length | 4000-15000mm |
4.Span of railway | 4000mm |
5.Railway length | 18000mm |
6.Speed of welding | 240-2400mm/min |
7.Position of welding | vessel welding |
8.Weld wire dimension | 3.2-5mm |
9.Flux recover | 100kg*2 |
10.Power of machine | 9kw |
3. Application
4. Packaging & Shipping
5. Our Services

¤ For more about our products, please feel free to contact us.
¤ Your satisfaction is our destination .
