3KVA Diesel Generator DMG3500LDE 0621
US$ 426 - 489
MOQ: 20 Sets
Key Specifications
Get Latest Price
Brand Name:
DOMIYA
Model Number:
DMG3500LDE
Output Type:
AC Single Phase
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5KVA Diesel Generator DMG6500LDE 0621US$ 446 - 510MOQ: 20 Sets -
1kw Gasoline Generator DM1600DC 0322US$ 75 - 100MOQ: 50 Sets
-
2.5kw Gasoline Generator DM3200CX 0322US$ 95 - 110MOQ: 50 Sets
-
2.5kw Gasoline Generator DM3800CXD 0322US$ 95 - 110MOQ: 50 Sets
-
5kw Gasoline Generator DM7800CXD 0323US$ 232 - 260MOQ: 50 Sets
Brand Name
DOMIYA
Model Number
DMG3500LDE
Output Type
AC Single Phase
Speed
3000/3600rpm
Frequency
50/60HZ
Rated Power
3kva
Rated Voltage
110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240
Product Description
Rated Frequency(hz): 50 60
Rated Voltage(v): 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240
Rated Output Power(kva): 2.8 3.0
Max Output Power(kva): 3.0 3.3
Rated Rotation Speed(rpm): 3000 3600
Power Factor (cos): 1.0
Phase Number: Single Phase
Noise Level Dba@7m: 70-74
Excitation Mode: Self-excitation Brushless
Engine Model: DM178FE
Engine Type: Single Cylinder, 4-Stroke, air-cooling, Direct Injection, Diesel Engine
Displacement MI Cu.in: 296(18.06)
Compression Ratio: 20:1
Rated Power Kw(hp)/rpm: 3.7(5.0)/3000 4.0(5.5)/3600
Starting System: E:Electric Starter
Rotation Direction
(view From Flywheel): Clockwise
Low Oil Pressure Alert System: with
Overall Dimension(LxWxH) Mm: 880 X 565 X 770
Dry Weight Kg: 140 Electric
Ref.QTY/20'FCl(SETS): 72
Rated Voltage(v): 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240
Rated Output Power(kva): 2.8 3.0
Max Output Power(kva): 3.0 3.3
Rated Rotation Speed(rpm): 3000 3600
Power Factor (cos): 1.0
Phase Number: Single Phase
Noise Level Dba@7m: 70-74
Excitation Mode: Self-excitation Brushless
Engine Model: DM178FE
Engine Type: Single Cylinder, 4-Stroke, air-cooling, Direct Injection, Diesel Engine
Displacement MI Cu.in: 296(18.06)
Compression Ratio: 20:1
Rated Power Kw(hp)/rpm: 3.7(5.0)/3000 4.0(5.5)/3600
Starting System: E:Electric Starter
Rotation Direction
(view From Flywheel): Clockwise
Low Oil Pressure Alert System: with
Overall Dimension(LxWxH) Mm: 880 X 565 X 770
Dry Weight Kg: 140 Electric
Ref.QTY/20'FCl(SETS): 72
Main Features
Air-cooled Diesel Generator Features:
Compact design, easy maintenance
Environmental adaptability, high reliability
Smooth running, low vibration, good start performance in low temperature
Less emissions, low operating costs
Optional Configurations for diesel generator:
1.Three Phase 2.. Hour Counter 3. Remote Control 4. ATS 5. Digital Panel
Optional Configurations for battery:
1. 12V-17ah 2. 12V-22ah 3. 12V-30ah 4. 12V-36ah
Certifications
Detailed Images
Our Service
Pre-Sales Service
visit the factory
After-Sales Service
* Training how to instal the machine, training how to use the machine.
