5KVA Diesel Generator DMG6500CL(E) 0620

FOB Price

US$ 325 - 400 / Set

50 Sets(Min. Order)

Port shanghai port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DOMIYA	Model Number	DMG6500CL(E)
Output Type	AC Single Phase	Speed	3000/3600rpm
Frequency	50/60HZ	Rated Power	5kva
Rated Voltage	110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240

Product Description

Rated Frequency(hz): 50 60

Rated Voltage(v): 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240

Rated Output Power(kva): 4.5 5.0

Max Output Power(kva): 5.0 5.5

Rated Rotation Speed(rpm): 3000 3600

Power Factor (cos): 1.0

Phase Number: Single Phase

Noise Level Dba@7m: 75-79

Excitation Mode: Self-excitation Brushless

Engine Model: DM186F/E

Engine Type: Single Cylinder, 4-Stroke, air-cooling, Direct Injection, Diesel Engine

Displacement MI Cu.in: 418(25.51)

Compression Ratio: 19:1

Rated Power Kw(hp)/rpm: 6.0(8.0)/3000 6.5(8.7)/3600

Starting System: Cl:recoil Starter

E:Electric Starter

Rotation Direction

(view From Flywheel): Clockwise

Low Oil Pressure Alert System: with

Overall Dimension(LxWxH) Mm: 740 X 500 X 670

Dry Weight Kg: 95 Recoi1 100 Electric

Ref.QTY/20'FCl(SETS): 99

Main Features

Air-cooled Diesel Generator Features:

Compact design, easy maintenance

Environmental adaptability, high reliability

Smooth running, low vibration, good start performance in low temperature

Less emissions, low operating costs

Optional Configurations for diesel generator:

1.Three Phase 2.. Hour Counter 3. Remote Control 4. ATS 5. Digital Panel

Optional Configurations for battery:

1. 12V-17ah 2. 12V-22ah 3. 12V-30ah 4. 12V-36ah

Certifications

Detailed Images

Our Service

Pre-Sales Service

visit the factory

After-Sales Service

* Training how to instal the machine, training how to use the machine.
