1. Chemical composition of the weldment
%C |
%Si |
%Mn |
%S |
%P |
≤ 0,09 |
≤ 0,35 |
≥ 0,40 |
≤ 0,030 |
≤ 0,030 |
2. Mechanical properties of the weldment:
|
Yield strength N/mm2 (Kgf/mm2) |
Tensile strength N/mm2 (Kgf/mm2) |
Elongation (%) |
Impact strength (J/cm2 -200C) |
σ0,2 ≥ 420 (41) |
σ0,2 ≥ 480 (48) |
δ5 ≥ 24 |
akv ≥ 70 |
3. Diameter and welding current:
|
Diameter (mm) |
Þ 2,5 |
Þ 3,2 |
Þ 4,0 |
Þ 5,0 |
|
|
Welding current (A) |
F |
50 ÷ 90 |
90 ÷ 140 |
140 ÷ 190 |
170 ÷ 240 |
V & OH |
50 ÷ 70 |
70 ÷ 120 |
120 ÷ 170 |
150 ÷ 220 |
|
4. Usage instructions: Suitable for welding structure of the carbon and low-alloy steel with thickness =< 30mm such as steel plate, building structure, machinery, bridge and road, pressure tank, ship building,...
5. Safety: The welding smoke and gas may affect your health. The arc may affect your eyes and burn your skin. The welding current is very dangerous. The protection wears should be worn. Do not touch the electric part during running.
