Trimble GPS TRIMBLE GPS RTK GNSS R8

Specifications

1.Powerful 440 channel solution
2.Advanced Satellite tracking with Trimble 360 technology

Trimble R8
positioning performance
code differential gnss positioning
Horizontal	0.25 m + 1 ppm RMS
Vertical	0.50 m + 1 ppm RMS
SBAS differential positioning accuracy	typically <5 m 3DRMS
static gnss surveying  high-precision static
Horizontal	3 mm + 0.1 ppm RMS
Vertical	3.5 mm + 0.4 ppm RMS
static and Faststatic
Horizontal	3 mm + 0.5 ppm RMS
Vertical	5 mm + 0.5 ppm RMS
postprocessed Kinematic (ppK) gnss surveying
Horizontal	8 mm + 1 ppm RMS
Vertical	15 mm + 1 ppm RMS
real time Kinematic surveying4 single baseline <30 km
Horizontal	8 mm + 1 ppm RMS
Vertical	15 mm + 1 ppm RMS
networK rtK
Horizontal	8 mm + 0.5 ppm RMS
Vertical	15 mm + 0.5 ppm RMS
Initialization time5	typically <8 seconds
Initialization reliability5	typically >99.9%
hardware
Dimensions (W×H)	19 cm × 10.2 cm
Weight	1.52 kg
Temperature6	40 °C to +65 °C
Humidity	100%, condensing
Water/dustproof	IP67
Shock and vibration	Tested and meets the following environmental standards
Shock	Non-operating
Vibration	MIL-STD-810F, FIG.514.5C-1







• Powerful 440 channel solution
• Advanced Satellite tracking with Trimble 360 technology
• Comprehensive support for all GNSS constellations and augmentation systems included as standard.
• Flexible wireless communication options for connecting to the controller, receiving RTK/network corrections and connecting to the internet.
• Web user interface and remote configuration.
